Higher Flexibility Marine Salvage Lift Bags Shortening The Project Cycle
Marine Rubber Airbag Used For Ship Launching , Landing And Salvage
Florescence inflatable rubber airbag is a kind of innovative product with our own intellectual property.It has been widely used in the ship launching and landing,the caissons lifting movement, the removal of other heavy objects, underwater installation work buoyancy aid and other areas. Marine airbag applications are not affected by site constraints, and don't need large-scale machinery and equipment,so that to shorten the project cycle and save a lot of money. After 20 years of development practice,prove that it is safe,efficient, green,and flexible.
Ship launching or upgrading relying on Florescence marine airbag is a innovative technology having utmost developmental prospect in shipbuilding.Ship launching airbags overcomes the disadvantage of fixed launching track by which the productive abilities of shipbuilding and ship repair were limited in the small and medium sized shipyards. Now it has become a flexible launching technology full of mobility, having advantages in saving effort,saving time,saving work load, saving investment,flexibility,safety, reliability, outstanding comprehensive economy benefit, flexible, safe, reliable, and outstanding benefit, etc. The launching technology of apply Florescence marine airbag to the launching and landing of ships overcomes the restrictions of traditional slide board technology which is commonly used in building small or medium size ships.
Advantages of Florescence marine rubber airbag
1. New design of anti-bursting construction at the end
2. High capacity against compression and twisting
3. Higher flexibility and damping capacity
Standard specifications of Florescence marine rubber airbag
1> Diameter (D): From 0.3m to 2.2 m.
2> Total Length (TL): From 7m to28m.
3> Other specification of ship launching airbags also available upon customer’s request
Working pressure of Florescence marine rubber airbag:
| Diameter | Layer | Work pressure | Diameter | Layer | Work pressure |
| D=0.8M | 3 | 0.13 Mpa | D=1.5M | 3 | 0.07 Mpa |
| 4 | 0.17 Mpa | 4 | 0.09 Mpa | ||
| 5 | 0.21 Mpa | 5 | 0.11 Mpa | ||
| 6 | 0.25 Mpa | 6 | 0.13 Mpa | ||
| 7 | 0.30 Mpa | 7 | 0.15 Mpa | ||
| 8 | 0.33 Mpa | 8 | 0.18 Mpa | ||
| D=1.0M | 3 | 0.10 Mpa | D=1.8M | 3 | 0.06 Mpa |
| 4 | 0.13 Mpa | 4 | 0.08 Mpa | ||
| 5 | 0.17 Mpa | 5 | 0.09 Mpa | ||
| 6 | 0.20 Mpa | 6 | 0.11 Mpa | ||
| 7 | 0.25 Mpa | 7 | 0.13 Mpa | ||
| 8 | 0.28 Mpa | 8 | 0.15 Mpa | ||
| D=1.2M | 3 | 0.09 Mpa | D=2.0M | 3 | 0.05 Mpa |
| 4 | 0.11 Mpa | 4 | 0.07 Mpa | ||
| 5 | 0.14 Mpa | 5 | 0.08 Mpa | ||
| 6 | 0.17 Mpa | 6 | 0.10 Mpa | ||
| 7 | 0.20 Mpa | 7 | 0.12 Mpa | ||
| 8 | 0.23 Mpa | 8 | 0.14 Mpa |
Our service
Pre-sale service:Every product will be inspected before shipment,guarantee the quality
On-sale service:Choose suitable package and transportation,gurantee the goods reach to customers safely,save freight for customers
After-sale service:One-to-one VIP service
We solemn promise:
1) Contact with customers statedly
2) Guide the installation and using of products
3) Provide maintenance manual of related products
4) Provide mending material for products
