High Performance Nc Straightener Feeder Machine 3.0mm Thickness
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
30 work days
Brand:
RUIHUI
Product Description
Welcome OEM & ODM
3 in 1 NC straightener machine of MAC1 series
Production:
MAC1 handles material up to 300~800mm width and 3.0mm thickness. This is the standard compact, high-performance straightener feeder system, and this model has been a best seller since it was put into the market.
It can be use in press line to help to make electronic products.
Specification:
| Model | MAC1-300 | MAC1-400 | MAC1-500 | MAC1-600 | MAC1-800 |
| Stock Width(mm) | 50~300 | 50~400 | 50~500 | 50~600 | 50~800 |
| Stock Thickness(mm) | 0.2~3.0 | 0.2~3.0 | 0.2~3.0 | 0.2~3.0 | 0.2~3.0 |
| Max.Coil Weight(kg) | 3000 | 3000 | 3000 | 3000~5000 | 5000~7000 |
| Max.Coil O.D.(mm) | 1200 | 1200 | 1200 | 1200 | 1200 |
| Coil I.D.(mm) | 508 | 508 | 508 | 508 | 508 |
| Feed Length(mm) | ~500* | ~500* | ~500* | ~500* | ~500* |
| Max.Line Speed(m/min) | 16~24 | 16~24 | 16~24 | 16~24 | 16~24 |
| Work Roll Number(piece) | Upper 4/lower 3 | ||||
| Feed Roll number(set) | 1 | 1 | 1 | 1 | 1 |
| Main Motor | AC2.0 | AC2.0 | AC2.0 | AC2.9 | AC4.4 |
| Mandrel Expansion | hydraulic | ||||
| Reel Motor(kw) | 1.5 | 1.5 | 1.5 | 2.2 | 3.7 |
| Power(v) | 3 Phase 220V/380V/50HZ | ||||
| Operating Air(Mpa) | 0.49 | 0.49 | 0.49 | 0.49 | 0.49 |
Straightening performance:
| Model | MAC1-300 | MAC1-400 | MAC1-500 | MAC1-600 | MAC1-800 | |
| Stock Thickness(mm) | 0.2 | 300 | 400 | 500 | 600 | 800 |
| 0.4 | ||||||
| 0.6 | ||||||
| 0.8 | 600 | |||||
| 1.0 | 500 | 500 | ||||
| 1.2 | 400 | 400 | 400 | |||
| 1.4 | 300 | 300 | 300 | 300 | ||
| 1.6 | 250 | 250 | 250 | 250 | 250 | |
| 2.0 | 190 | 190 | 190 | 190 | 190 | |
| 2.3 | 160 | 160 | 160 | 160 | 160 | |
| 3.0 | 100 | 100 | 100 | 100 | 100 | |
*The above flgures are the material having yied strength of 245N/mm2
FAQ:
Q1:What kinds of machines do you have?
Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener
Feeder,Transfer systems,Press Feeding Line., etc
Q2:Is your equipment standard or customized?
Both, we can OEM & ODM with customers.
Q3:What are your equipments certification?
All our items are coming with CE certifications.
Q4:How did your company's quality system work?
“QUALITY IS OUR CULTURE” Our quality is not the best in the world, and the price is not the
cheapest. But we can provide you excellent products to defeat your competitors.
Q5:How long is the warranty period of the machine?
We offer free service with a warranty period of one year, If it is operate in reasonable, the
machine can be used more than 10 years.
Q6: Is it possible to be a foreign agent and distributor?
If you are confidence and excellent service for after-sales, then welcome to be our agents or
distributors all over the world.
Q7:What’s your payment?
T/T,D/P,L/C,Western Union., etc
Q8:What’s the delivery?
“TIME IS GOLD” for you and for us, so we have professional team work and production line can
make nice quality in short time.
Service:
1. Pre-Sales Service:We have professional designers to meet the different requirement.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.![]()
