Eaton Disc Valve Motor 109-1196-006 Orbit Motor 1 1/2 Inch 17 T Splined Shaft Standard SAE C Mount

Price Negotiable
Price: contact seller to get a quote
MOQ: 100 Sets
Delivery Time: 65 work days
Brand: HANJIU
Product Description

eaton disc valve motor 109-1196-006 orbit motor, 1 1/4 Inch 17 T Splined shaft Standard SAE C mount



Quick review:

109-1196-006   BMK4-315-AC-C-S
Model Code:   M04190AF10AC0300000000000AA00F
Feature Code Description
PRODUCT M MOTOR
SERIES 04 4000 SERIES
DISPLACEMENT 190 311.8 CM3/R [19.03 IN3/R]
MOUNTING TYPE AF STANDARD, 4 BOLT; 127.00 [5.000] PILOT DIA.14.27 [.562] DIA. HOLES ON 161.92 [6.375] DIA. BOLT CIRCLE. (SAE C)
OUTPUT SHAFT 10 38.10 [1.500] DIA. FLAT ROOT SIDE FIT, 17 TOOTH, 12/24 DP 30 DEG. INVOLUTE SPLINE, 31.2 [1.23] MINIMUM FULL SPLINE LENGTH, WITH .375-16 UNC-2B THREAD IN END
PORTS AB 1.0625-12 UN-2B SAE O-RING PORTS - STAGGERED PORTS
FLOW OPTIONS 2 .4375-20 UNF-2B SAE O-RING PORT WITH CHECK VALVE
LOW PRESSURE RELIEF 0 NONE
PRESSURE/FLOW OPTION 0 NONE
GEROLER OPTION 0 STANDARD
SEAL OPTION 0 STANDARD
ACCESSORIES 0 NONE
SPECIAL FEATURES (HARDWARE) 0 NONE
SPECIAL FEATURES (ASSEMBLY) 0 NONE
PAINT/PACKAGING 0 NO PAINT, INDIVIDUAL BOX








Application


Mowing, Snow Removal, Sprayer, Trencher, Wood Products

















To get the most competitive price for a hydraulic orbital motor, consider the following



Compare multiple suppliers Get quotes from different manufacturers and distributors.

Specify your requirements clearly Clearly outline your motor's specifications to avoid unnecessary costs.

Consider refurbished or rebuilt options These can be more cost-effective.

Negotiate Don't be afraid to negotiate the price, especially for bulk purchases.

If you have specific requirements for your application, I can help you find potential suppliers or provide more accurate pricing information.



Would you like to provide more details about the orbital motor you need, such as displacement, torque, speed, and application



This information will help me narrow down your options and provide more specific pricing information.



Additionally, you can use online marketplaces and industrial equipment suppliers to get a general idea of pricing for different models.



This is talk new business chance, new profit growth methods, while maintain and carry forward your public praise. We, HANJIU, hydraulic manufacturer from China are willing to try to be your another choice. We provide Ogniben, M +S, Sauer Dan foss, EATON, Char-Lynn alternative Hydraulic Motors, Orbitrol, Control Valve with super strong price advantage.
