Professional Hydraulic Wheel Motor / Hydraulic Drive Device Engine BMSW315 / 3W 315Z2AY

Price Negotiable

Price: Negotiable

MOQ: 30 Sets

Delivery Time: 10-15 work days

Brand: HANJIU

Product Description

Hydraulic Wheel Motor / Hydraulic Drive Device Engine BMSW315 / 3W 315Z2AY

Introduction

A simultaneous maximum torque and maximum speed NOT recommended.
Bar-True pressure difference between inlet port and outlet port.
Continuous Rating-Motor may be run continuously at these ratings.
Intermittent Operation-10% of very minute
To assure best more life, run motor for approximately one hour at 30% of rated pressure before application to full load. Be sure motor is filled with fluid prior to any load applications.

Feature

Compact size, high efficiency
Low-friction and long life advantages
Internal check valves, Escort seal
This motor has a rugged housing with an extra large capacity side load bearing
Shaft seal can bear high pressure of back and the motor can be used in parallel or series
Geroler and drive use the SMT series motors parameter, prolong operating life.

YPE		BMSW-315	BMSW-400	BMSW-500	BMSW-630	BMSW-800	BMSW-985
Displacement(ml/r)		314.9	399.7	496.6	617.8	787.4	969.1
Max.Pressure.Drop(Mpa)	cont.	20	20	20	18	16	14
	int.	24	24	24	21	18	16
	peak.	28	28	28	24	21	18
Max.Torque(N.m)	cont.	873	1108	1385	1570	1773	1900
	int.	1119	1440	1783	1951	2122	2133
	peak.	1293	1650	2060	2249	2481	2399
Speed.Range(cont.)(r/min)		10-475	9-375	8-300	6-238	5-187	5-154
Max.Flow(cont.)(L/min)		150	150	150	150	150	150
Max.Output.Power(cont.)(Kw)		32	32	32	32	32	24
Weight(kg)		30.7	31.5	32.4	33.6	35.2	37.2

3. Applications:

HANJIU Wheel Motor Orbital type is one type of high torque low speed hydraulic motors, with high efficiency and long life. Which can be widely used for kinds of Rollers, Heavey Machines, Construction Machines etc. To know more details,like technical data or drawing, pls directly contact us or to download from our main website.
