Economical Type Hydraulic Steering Unit 101S For Agriculture Tractor Steering
Hydraulic Steering Unit 101S For Tractor FORD , Tractor OEM Parts
♦ Characteristic Features
1. 101s Hydraulic steering unit with relief valve, suction valve, inlet check valve intergrated different valve.
2. Replace (OSPC), M+S (HKUS) series.
3. Hydraulic steering unit 101s match with Tractor OEM Part Number.
♦ Specification
| Parameters | Series 101S-*-***-**-* |
||||||||||
| Function code | 1,2,4 | 1,4 | |||||||||
| Displacement (mL/r) | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 | 280 | 315 | 400 |
| Rated Flow (L/min) | 5 | 6 | 8 | 10 | 12.5 | 16 | 20 | 25 | 28 | 32 | 40 |
| Max.input pressure(Mpa) | 16 | ||||||||||
| Relief Valve Pressure Settings ( MPa) | 06,07,08,10,12,14,15,16 | ||||||||||
| Shock Valve Pressure Settings ( MPa) | 12,13,14,16,18,20,21,22 | ||||||||||
| Max.cont.back pressure | 2.5 | ||||||||||
| Weight(kg) | 5.75 | 5.81 | 5.89 | 5.96 | 6.1 | 6.3 | 6.5 | 6.73 | 6.91 | 7.1 | 7.5 |
| Dimension L (mm) | 130 | 132 | 134 | 137 | 140 | 145 | 150 | 156 | 161 | 166 | 176 |
♦ Application
Tractor FORD and Hydraulic steering unit OEM Parts
|
OEM Number AL55954 / AL28268 / AL35832 |
Hydraulic Steering Unit 101S-100 / OSPB100CN |
Application 1640, 2040, 2140, 3040, 3140, 3340 |
|
OEM Number AL55956 / AL32758 / AL35834 |
Hydraulic steering unit 101S-160 / OSPB160CN |
Application 1640, 2040, 2140, 3040, 3140, 3340 |
|
OEM Number AL41604 |
Hydraulic steering unit 101S-100 / OSPC100CN |
Application 2140, 2141, 2541 2941, 3141, 3641, 1641, 2251 2351, 2651, 2951, 3351, 3651 |
|
OEM Number AL55308 |
Hydraulic steering unit 101S-100 / OSPC100CN |
Application 3050, 3350, 2650, 2850, 2250, 2450, 1550, 1750, 1850 |
|
OEM Number AL41631 |
Hydraulic steering unit 101S-125 / OSPC125CN |
Application 1640, 2040, 3050, 3350, 2650, 2850, 2250, 2450, 1550, 1750, 1850, 1950 |
|
OEM Number AL41291 |
Hydraulic steering unit 101S-160 / OSPC160CN |
Application 1640, 2040, 2140, 3040, 3140, 2141, 2541, 2941, 3141, 3641, 2251, 2351, 2651, 2951, 3351, 3050, 3350 |
|
OEM Number AL55296 |
Hydraulic steering unit 101S-200 / OSPC200CN |
Application 3040, 3140, 3640, 3050, 3350, 3650 |
|
FORD OEM Number 5165135 / 5143323 / 5170488 5143325 / 5170489 |
Hydraulic steering unit 101S-100/ OSPC100ON |
Application FORD 3435, 3830, 3935, 4030, 4135, 4230, 4430 |
|
FORD OEM Number 81863665 |
Hydraulic steering unit 101S-150/ OSPC150O |
Application FORD 5640, 6640, 7740, 7840, 8240, 8340 |
| All Tractor OEM Number | All Type Steering Unit | All Tractor Brand |
