BMRW 315 Hydrostatic Wheel Motors , Hydraulic Track Motor For Scag / Turf Tiger
Price:
Negotiable
MOQ:
10 Pieces
Delivery Time:
10 - 15 work days
Brand:
HANJIU
Product Description
Hydraulic Wheel Motor For Scag, Turf Tiger, Tiger Cub and Wildcat Mowers 482639
PRODUCT INTRODUCE:
- Replaces (OEM): PARKER TF0240LS080AAFB
- Replace SCAG 481529, 482639
- Replace OEM: Bobcat 4159280
- Replace OEM: Parker TF0240LS080AAFB, TF0240LS080AAKY
- Fits Most SCAG Turf Tiger, Tiger Cub, and Wildcat Models.
- 12 months warranty from date of professional installation
- High volumetric efficiency
- High starting torque
- Heavy-duty bearings
- Direct drive so no gears required
When ordering and replacing a hydro pump, always replace the wheel motor and lines, flush the tanks and install a new oil filter. Not doing so could cause the hydro pump to fail due to contamination in the system.
PRODUCT APPLICATIONS:
- Skid Steer Loaders
- Fairway Mowers
- Harvesters
- Vehicles where space
- Snow removal
- Agricultural sprayers
- Trenchers
- Wood mill products
- Brush cutters
- Mower
- Haveresting equipment
- Forestry equipment
- Turf equipment
TYPE |
BMR-50 BMRW-50 BMRS-50 |
BMR-80 BMRW-80 BMRS-80 |
BMR-100 BMRW-100 BMRS-100 |
BMR-125 BMRW-125 BMRS-125 |
BMR-160 BMRW-160 BMRS-160 |
BMR-200 BMRW-200 BMRS-200 |
BMR-250 BMRW-250 BMRS-250 |
BMR-315 BMRW-315 BMRS-315 |
BMR-400 BMRW-400 BMRS-400 |
|
| (ml/r) Displacement |
51.7 | 80.5 | 100.5 | 126.3 | 160.8 | 200.9 | 252.6 | 321.5 | 401.9 | |
| Max.Pressure.Drop(Mpa) | cont. | 14 | 14 | 14 | 14 | 14 | 14 | 11 | 9 | 7 |
| int. | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 11 | 9 | |
| peak. | 20 | 20 | 20 | 20 | 20 | 20 | 16 | 13 | 11 | |
| Max.Torque(N.m) | cont. | 93 | 152 | 194 | 237 | 310 | 369 | 380 | 380 | 380 |
| int. | 118 | 189 | 236 | 296 | 378 | 450 | 470 | 470 | 470 | |
| peak. | 135 | 216 | 270 | 338 | 433 | 509 | 540 | 540 | 540 | |
| Speed.Range(cont.)(r/min) | 10-775 | 10-750 | 10-600 | 10-475 | 10-375 | 10-300 | 10-240 | 10-190 | 10-160 | |
| Max.Flow(cont.)(L/min) | 40 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | |
| Max.Output.Power(cont.)(Kw) | 7 | 10 | 10 | 10 | 10 | 8 | 6 | 5 | 4 | |
| Weight(kg) | 6.5 | 6.9 | 7.0 | 7.3 | 7.5 | 8.0 | 8.5 | 9.0 | 11 | |
Please do not hesitate to contact us for further information, inquiries or orders.
Thank you for choosing 'Hanjiu' Hydraulics.
