25mm Shaft Hydraulic Rotary Motor Hitachi Drive Shortmotor OZ 160ml/R
Hydraulic Motor Hitachi Drive Shortmotor OZ 160ml/r, 25mm shaft, 2-bolt mounting
Quick details:
- we produce hydraulic motors for Heavy duty vehicles, Ag machinery, Special vehicles
- variety version available from OZ, OK, BMM, BMP, BMR, BMH, BMS, BMT, BMV, BMK2, BMK6, BMER
- variety types with same specifications with most Eaton Char-lynn, , Parker, and many more
- OZ series motor are small volume,
- economical type,
- designed with shaft distribution flow,which adapt the Gerotor gear set design and
- provide compact volume, high power and low weight.
Features:
- Advanced manufacturing devices for the Gerotor gear set, which provide
- small volume, high efficiency and long life.
- Shaft seal can bear high pressure of motor of which can be used in parallel or in series.
- Advanced construction design, high power and low weight.
Applications:
This OZ series hydraulic motors is a slow speed high torque type hydraulic motors, they are widely used on Farmland irrigation winch, Towing and mooring winches, Cable Laying winch, Oceanographic research winch, Nautical equipment and winches for fishing boats, Winch as an anchor, Capestani, Special systems for subsea pipelay, Winch Wood from deforestation, Wood processing and cutting machines, Agricultural and forestry machinery, Construction machinery and platform, Ground care and Mowing machinery, etc.
Main Specification:
| Main Specifications: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technical data for BMP with 25 and 1 in and 1 in splined and 28.56 tapered shaft: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Specification Data of Hydraulic Motors | |||||
| Distribution type | Model | Displacement | Max. operating pressure | Speed range | Max. output power |
| (cm3/rev.) | (MPa) | (rpm) | (kW) | ||
| Axial distribution | BMM | 8-50 | 14 | 30-1950 | 3.2 |
| BMP | 36-400 | 16.5 | 30-879 | 10 | |
| BMR | 36-375 | 20 | 30-970 | 15 | |
| BMH | 200-500 | 20 | 30-430 | 17 | |
| Specification Data of Hydraulic Motor | |||||
| Distribution type | Model | Displacement | Max. operating pressure | Speed range | Max. output power |
| (cm3/rev.) | (MPa) | (rpm) | (kW) | ||
| Disc distribution | BMS | 80-475 | 22.5 | 30-800 | 24 |
| BMT | 160-800 | 24 | 30-705 | 35 | |
| BMV | 315-800 | 28 | 10-446 | 43 | |
