Turf Equipment Hydraulic Motor Assembly Parker TE0230CW410AAAB Replacement TE 0230 230cm³
Price:
Negotiable
MOQ:
100 Sets
Delivery Time:
25 - 35 work days
Brand:
HANJIU
Product Description
Turf equipment Hydraulic Motor Assembly, Parker TE0230CW410AAAB replacement, TE 0230, 230cm³
Displacement: 230cm³
Mounting : SAE "A" 2 Bolt, Long Pilot
Ports : G 1/2 BSPP
Shaft : Long 6B Spline
Rotation : Standard
Low speed high torque motor :
Low speed high torque hydraulic motor are rotary actuators that convert hydraulic, or fluid energy into mechanical power. They work in tandem with a hydraulic pump, which converts mechanical power into fluid, or hydraulic power. Hydraulic motors provide the force and supply the motion to move an external load.
| type |
BMER 125 |
BMER 160 |
BMER 200 |
BMER 230 |
BMER 250 |
BMER 300 |
BMER 350 |
BMER 375 |
BMER 400 |
BMER 475 |
BMER 540 |
BMER 650 |
BMER 750 |
|
| Max. speed (rpm) | cont. | 360 | 375 | 330 | 290 | 290 | 250 | 220 | 200 | 185 | 160 | 140 | 115 | 100 |
| int. | 490 | 470 | 425 | 365 | 350 | 315 | 270 | 240 | 220 | 195 | 170 | 138 | 120 | |
| Max. torque (N•m) | cont. | 325 | 450 | 530 | 625 | 700 | 810 | 905 | 990 | 1010 | 1085 | 980 | 1015 | 1050 |
| int. | 380 | 525 | 600 | 710 | 790 | 930 | 1035 | 1140 | 1180 | 1180 | 1240 | 1250 | 1180 | |
| peak | 450 | 590 | 750 | 870 | 980 | 1120 | 1285 | 1360 | 1360 | 1260 | 1380 | 1380 | 1370 | |
| Max. output (kW) | cont. | 12 | 15 | 15.5 | 16 | 17.5 | 18 | 17.5 | 16.5 | 15.5 | 14.5 | 11.5 | 10 | 8 |
| int. | 14 | 17.5 | 18 | 19 | 20 | 21 | 20 | 19 | 18 | 16.5 | 15 | 12 | 10 | |
| Max. pressur drop e (MPa) | cont. | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20. 5 | 20.5 | 19 | 17.5 | 14 | 12 | 10.5 |
| int. | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 22.5 | 19 | 17.5 | 15.5 | 12 | |
| peak | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 25 | 20.5 | 20.5 | 17.5 | 14 | |
| Max. flow (L/min) | cont. | 45 | 60 | 70 | 70 | 75 | 80 | 80 | 75 | 75 | 75 | 75 | 75 | 75 |
| int. | 60 | 75 | 85 | 85 | 90 | 95 | 95 | 90 | 90 | 90 | 90 | 90 | 90 |
|
| Parker Items | Hanjiu Replacement |
| TE0130LW260AAAB | BME2-130 |
| TE0050CW410AAAB | BME2-50 |
| TE0165CW410AAAB | BME2-165 |
| TE0230LW260AAAB | BME2-230 |
| TE0080LW260AAAB | BME2-80 |
| TF0240HW460AAAB | BMER-250 |
| TG0530HW460AAAB | BMER-530 |
| TG0335HW460AAAB | BMER-350 |
| TG0475US080AAAA | BMER-475 |
| TG0280US080AAX1 (DMA210218) | BMER-280 |
| TF0280MS030AAAA | BMER300 |
| TE0195US250AAKY | BME2-200 |
| TG0475HV450AAA | BMER-475 |
| TG0240HK460AAAB | BMER--240 |
| TK0500K5360AAAB | BMTE-500 |
