Danfoss OMT 315 Hydraulic Orbit Motor 4 Bolts Tapered Shaft BSP Port Threads
Price:
Negotiable
MOQ:
20 Sets
Delivery Time:
Negotiable
Brand:
HANJIU
Product Description
Danfoss OMT 315 Motor 4 Bolts Hydraulic orbit motor tapered shaft BSP Port threads
- Output volume (cc/rev): 326.3
- Shaft: cone shaft 1.5 inch
- max r.p.m.: 380
- Torque max. (Nm): 950/1140
- Power max. (kW): 30
- Pressure difference (bar): 180
- Inlet pressure (bar): 280
- Volume flow max. (l/min): 125
- Engine version: with non-return valves
- Connection: G 3/4"
- Leakage oil connection: G 1/4"
Main Specifications:
| Type | BMT 160 |
BMT 200 |
BMT 230 |
BMT 250 |
BMT 315 |
BMT 400 |
BMT 500 |
BMT 630 |
BMT 800 |
|
| displacement (cm3/rev. ) | 161.1 | 201.4 | 232.5 | 251.8 | 326.3 | 410.9 | 523.6 | 629.1 | 801.8 | |
| Max. speed (rpm) |
cont. | 625 | 625 | 536 | 500 | 380 | 305 | 240 | 196 | 154 |
| int. | 780 | 750 | 643 | 600 | 460 | 365 | 285 | 233 | 185 | |
| Max. torque (N.m) | cont. | 470 | 590 | 670 | 730 | 950 | 1080 | 1220 | 1318 | 1464 |
| int. | 560 | 710 | 821 | 880 | 1140 | 1260 | 1370 | 1498 | 1520 | |
| peak | 669 | 838 | 958 | 1036 | 1346.3 | 1450.3 | 1643.8 | 1618.8 | 1665 | |
| Max. output (KW) | cont. | 27.7 | 34.9 | 34.7 | 34.5 | 34.9 | 31.2 | 28.8 | 25.3 | 22.2 |
| int. | 32 | 40 | 40 | 40 | 40 | 35 | 35 | 27.5 | 26.8 | |
| Max.pressure drop (MPa) | cont. | 20 | 20 | 20 | 20 | 20 | 18 | 16 | 14 | 12.5 |
| int. | 24 | 24 | 24 | 24 | 24 | 21 | 18 | 16 | 13 | |
| peak | 28 | 28 | 28 | 28 | 28 | 24 | 21 | 19 | 16 | |
| Max. flow (L/min) | rated | 80 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| cont. | 100 | 125 | 125 | 125 | 125 | 125 | 125 | 125 | 125 | |
| int. | 125 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | |
| Max. inlet pressure (Mpa) |
cont. | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 |
| int. | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| peak | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | |
| Weight (kg) | 19.5 | 20 | 20.4 | 20.5 | 21 | 22 | 23 | 24 | 25 | |
other types we supply same as Danfoss
151B3009 OMT 315
151B3010 OMT 400
151B3011 OMT 500
151B3012 OMT 160
151B3013 OMT 200
151B3014 OMT 250
151B3015 OMT 315
151B3016 OMT 400
151B3017 OMT 500
151B3018 OMT 160
151B3019 OMT 200
151B3020 OMT 250
151B3021 OMT 315
151B3022 OMT 400
151B3023 OMT 500
151B3042 OMT 160
151B3043 OMT 200
151B3044 OMT 250
151B3045 OMT 315
151B3056 OMT 250
151B3057 OMT 400
151B3062 OMT 500
