Harvester hydraulic solutions hydraulic valve P40 with floating

Quick review:

Max operating pressure P = 3600psi (250 bar); T = 150psi (10 bar); A , B = 4300psi (300 bar)
Tandem center, all spools are double acting with spring return in neutral position
A, B ports 1/2' BSPP; P, T, N ports 1/2' BSPP (British Standard Parallel Pipe, not NPT)
Adjustable relief valve: from 1500 to 3625 PSI
specify if you need special spools, adapters, power beyond etc

We provide solutions for agricultural machinery hydraulic system, harvester hydraulic valve with floating function is one of them.

At the same time, we also provide hydraulic solutions for agricultural equipment such as tractors, two-headed, flatbed trucks, truck-mounted cranes, corn harvesters, wheat harvesters, large weeders, peanut harvesting/fruit picking machines, and agricultural equipment such as sprayers. .

In addition to agricultural machinery, we also provide drilling rigs, cranes, flatbed trucks, special operation vehicles (sanitation trucks, garbage trucks, road sweepers), dump trucks, truck-mounted cranes and other construction machinery, wood splitters, drilling rigs, truck-mounted cranes, modified Hydraulic solutions are provided for excavators, machinery that changes the action of excavators, scissor-type aerial work vehicles, loaders, forklifts (oil forks), drilling rig travel valves, drilling rig unloading valves, tractors, loaders and other engineering mobile equipment.

There are many types of flow, installation, models, sizes, and types. Welcome to contact us for cooperation.
