10T 15T 20T 50T 5Ton Wire Rope Crane Hoist Single And Double Speed
Price:
Negotiable
MOQ:
1 set
Delivery Time:
15 to 20 working days
Brand:
JCYC
Product Description
CD / MD 10T 15T 20T 50T 5Ton Electric Wire Rope Hoist Single and Double Speed Electric Cable Hoist
Product Description:
CD and MD type wire rope electric hoist descriptions:
The CD and MD type wire rope electric hoist is a kind of light and small lifting equipment, which can be installed in single beam crane, bridge crane, gantry crane, cantilever crane, etc. They can meet the requirements of ordinary occasions.
The CD and MD type wire rope electric hoist is a kind of light and small lifting equipment, which can be installed in single beam crane, bridge crane, gantry crane, cantilever crane, etc. They can meet the requirements of ordinary occasions.
The electric wire rope hoist model CD and MD have the features of compact, light, small-size shape and smooth operation. It can be used not only on the overhead rails, but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane, the double girder crane, the cantilever crane and the gantry crane. The electric hoist model MD1 with double lifting speed should be used in cases where the hoist model CD1 with single speed cannot meet the requirements for fine adjusting during precision operations.
Product Parameters:
JCYC-CD1 Electric Wire Rope Hoist
| Model | Lifting Capacity (t) | Lifting Height (m) | Lifting Speed (m/min) | Running Speed (m/min) | Wire Rope Type |
Dia. of Wire Rope (mm) |
I Beam Track Type | Working Duty | Lifting Motor |
Running Motor |
||||
|
Power (kw) |
R.P.M | Power Supply |
Power (kw) |
R.P.M | Power Supply | |||||||||
| CD1-0.25 | 0.25 | 3-9 | 8 | 20 | 6*19 | 3.6 | 16-22b | M3 | 0.4 | 1380 | 220-440V 50/60HZ 3Phase |
0.06 |
1400 | 220-440V 50/60HZ 3Phase |
| CD1-0.5 | 0.5 | 6-12 | 8 | 20 | 6*37+1 | 4.8 | 16-28b | M3 | 0.8 | 1380 | 0.2 | 1380 | ||
| CD1-1 | 1 | 6-30 | 8 | 20 | 6*37+1 | 7.4 | 16-28b | M3 | 1.5 | 1380 | 0.2 | 1380 | ||
| CD1-2 | 2 | 6-30 | 8 | 20 | 6*37+1 | 11 | 20a-32c | M3 | 3 | 1380 | 0.4 | 1380 | ||
| CD1-3 | 3 | 6-30 | 8 | 20 | 6*37+1 | 13 | 20a-32c | M3 | 4.5 | 1380 | 0.4 | 1380 | ||
| CD1-5 | 5 | 6-30 | 8 | 20 | 6*37+1 | 15 | 25a-63c | M3 | 7.5 | 1380 | 0.8 | 1380 | ||
| CD1-10 | 10 | 6-30 | 7 | 20 | 6*37+1 | 15 | 25a-63c | M3 | 13 | 1400 | 0.8*2 | 1380 | ||
| CD1-16 | 16 | 6-30 | 3.5 | 20 | 6*37+1 | 15 | 45a-63c | M2 | 13 | 1400 | 0.8*2 | 1380 | ||
| CD1-20 | 20 | 6-30 | 3.5 | 20 | 6*37+1 | 20 | 50a-63c | M2 | 13 | 1400 | 0.8*2 | 1380 | ||
JCYC-MD1 Electric Wire Rope Hoist
| Model | Lifting Capacity (t) | Lifting Height (m) | Lifting Speed (m/min) | Running Speed (m/min) | Wire Rope Type | Dia.of Wire Rope (mm) | I Beam Track Type | Working Duty | Lifting Motor | Running Motor | ||||
|
Power (kw) |
R.P.M ( r/min) | Power Supply |
Power (kw) |
R.P.M ( r/min) | Power Supply | |||||||||
| MD1-0.25 | 0.25 | 3-9 | 8/0.8 | 20 | 6*19 | 3.6 | 16-22b | M3 | 0.4 | 1380 | 220-440V 50/60HZ 3Phase | 0.06 | 1400 | 220-440V 50/60HZ 3Phase |
| MD1-0.5 | 0.5 | 6-12 | 8/0.8 | 20 | 6*37+1 | 4.8 | 16-28b | M3 | 0.2/0.8 | 1380 | 0.2 | 1380 | ||
| MD1-1 | 1 | 6-30 | 8/0.8 | 20 | 6*37+1 | 7.4 | 16-28b | M3 | 0.2/1.5 | 1380 | 0.2 | 1380 | ||
| MD1-2 | 2 | 6-30 | 8/0.8 | 20 | 6*37+1 | 11 | 20a-32c | M3 | 0.4/3.0 | 1380 | 0.4 | 1380 | ||
| MD1-3 | 3 | 6-30 | 8/0.8 | 20 | 6*37+1 | 13 | 20a-32c | M3 | 0.4/4.5 | 1380 | 0.4 | 1380 | ||
| MD1-5 | 5 | 6-30 | 8/0.8 | 20 | 6*37+1 | 15 | 25a-63c | M3 | 0.8/7.5 | 1380 | 0.8 | 1380 | ||
| MD1-10 | 10 | 6-30 | 7/0.7 | 20 | 6*37+1 | 15 | 25a-63c | M3 | 1.5/13 | 1400 | 0.8*2 | 1380 | ||
| MD1-16 | 16 | 6-30 | 3.5/0.35 | 20 | 6*37+1 | 15 | 45a-63c | M2 | 1.5/13 | 1400 | 0.8*2 | 1380 | ||
| MD1-20 | 20 | 6-30 | 3.5/0.35 | 20 | 6*37+1 | 20 | 50a-63c | M2 | 1.5/13 | 1400 | 0.8*2 | 1380 | ||
Product Packing:
