Commercial Stretched Wall Mount Lcd Display 28 Inch 697.7 * 130.7mm For Subway
28 Inch Commercial Grade HD BAR Display 500 NIT Advertising Video Player Stretched LCD Display
1. Bar Display deliver the right message at the right time to the right customer consistently at every location and make real-time adjustments to stay ahead of your competition.
2. Digital stretch display can help your business in many ways from altering consumer behaviors at the point of sale, enhancing your brand, scheduling your promotions during peak periods, managing your signage from a central location to increasing cross-selling and up-selling opportunities.
3. Resized LCD display attract more consumers' attention and provide FHD displaying experience.
4. Can be with Android mainboard, displaying will fit screen automatically.
5. Can be with Monitor mainboard, has HD.MI in, DVI in and VGA in.
| Panel Specification | |
| Panel Size | 28inch |
| Display area | 697.7*130.7mm |
| Brand | Samsung/Lg/Auo A grade new panel |
| Resolution | 1366*256 |
| Display Color | 16.7M |
| Pixel Pitch | 0.51075MM X 0.51075MM |
| Brightness | 600cd/m*2 |
| Back Light | LED |
| Aspect ratio | 16:03 |
| Response time | 8MS |
| Contrast | 1500:1 |
| View angle | 89/89/89/89 |
| Life time | > 50,000 hours |
| Video Specification | |
| Resolution | 1366*256 |
| Video Format | RM/RMVB, MKV, TS, FLV, AVI, VOB, MOV, WMV, MP4 etc |
| Audio Format | MP3, WMA, APE, Flac etc |
| Picture Format | JPG, BMP, GIF etc |
| Input Function | |
| Multi touch(Infrared/Resistance/Capacitive) | Support |
| Remote control | Support |
| USB Mouse/Keyboard | Support |
| Output Function | |
| Horizontal/Vertical Showing Mode | Support |
| 1080P HD Dot to Dot oIutput | Support |
| LVDS/HDMI/VGA/AV | Support |
| Advantages | |
| Time Switch | Turn on/off automatically |
| Rolled Text | Showing on the bottom of the panel |
| Calendar | Support |
| Weather | Support |
| Logo | Support |
| Splicing Screen | Support Video/photos/rolled text/weather/Calendar/logo showing in the same screen at the same time |
| Main Board Specification | |
| Mainboard | 6M182 |
| Flash Memory | 8GB SD card |
| USB | 1 |
| Audio | built-in HD audio 8(Realtek ALC888) audio system |
| Playing Mode | Insert USB or SD card |
| OSD Language | |
| Menu Language | Chinese, English |
| Environment | |
| Working Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Working Humidity | 20%-80% |
| Storage humidity | 5%~95% |
| Power | |
| Power Supply | DC +12V |
| Maximum power consumption | <=4.5W |
| Standby power consumption | <=1W |
| Appearance | |
| Dimension | 1039(H)mm*632(W)mm*90(D)mm |
| NetWeight | 25kgs/pcs |
| Color | White, Black, Silver, Golden, Customize based on Pantone number |
| Material | Cold Rolled Steel, Aluminum, Stainless Steel |
| Installation | mounted on the wall |
| Certificcates | CE/FCC/ROHS/C-TICK/BV/SASO |
| Accessories | CD, Screws, Keys, Power Cable, Warranty Card, User Manual |
| Package | |
| Package Step | Foam+Carton box+Wooden box |
| Package Dimension | 130*12*90cm/pcs/wooden box |
| Gross Weight | 50kgs/pcs/wooden box |
