600mm x 600mm x 40mm crane foot support blocks with nylon rope
Price:
USD 15-40 / piece Fob Qingdao
MOQ:
1 pcs
Delivery Time:
10-15 days after order confirmation .
Brand:
Shengtong
Product Description
600mm x 600mm x 40mm crane foot support blocks with nylon rope
Specification
| Square Outrigger Pad | Round Outrigger Pad | ||
| Common size | Loading capacity for crane feed | Common size | Loading capacity for crane feed |
| 300*300*40mm | 3-5 tons | 300*40mm | 2-6 tons |
| 400*400*40mm | 4-6 tons | 400*40mm | 3-7 tons |
| 400*400*50mm | 6-10 tons | 500*40mm | 4-8 tons |
| 500*500*40mm | 10-12 tons | 500*50mm | 8-12 tons |
| 500*500*50mm | 12-15 tons | 600*40mm | 10-14 tons |
| 500*500*60mm | 13-17 tons | 600*50mm | 12-15 tons |
| 600*600*40mm | 15-18 tons | 600*60mm | 15-25 tons |
| 600*600*50mm | 16-20 tons | 700*50mm | 22-30 tons |
| 600*600*60mm | 18-25 tons | 700*60mm | 25-32 tons |
1000mm x 1000mm
1200mm x 1200mm
max thickness 200mm
cut to small size and loadinc capacity from 10 tons to 250 tons.
The color of Crane Outrigger Pad
White,Black,Red,Blue,Green,Yellow,Orange etc
