GYTS Fiber Optic Cable Underground GYTS PSP Steel Tape Armoured Single Mode
GYTS Fiber Optic Cable Underground GYTS PSP Steel Tape Armoured Single mode
GYTS Optical Fiber Cable Underground GYTS PSP Steel Tape Armoured Single mode 12 24 48 72 Outdoor Optical Fiber Cable
The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. The PSP is longitudinally applied over the cable core, which is filled with the filling compound to protect it from water ingress. The cable is completed with a PE sheath.
Characteristics
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- Specially designed compact structure is good at preventing loose tubes from shrinking
- Crush resistance and flexibility
- PE sheath protects cable from ultraviolet radiation
- The following measures are taken to ensure the cable watertight:
- Steel wire used as the central strength member
- Loose tube filling compound
- 100% cable core filling
- PSP enhancing moisture-proof
Standards: IEC 60794-1
Technical Parameters
| Part No. | Fibers | Tubes |
Cable OD (mm) |
Weight Kg/km |
Tensile strength Long term/short term (N/1m) |
Crush resistance Long term/short term (N/1m) |
Bending Radius Static/Dynamic (mm) |
| GYTS-2~6X | 2~6 | 1 | 9.5 | 100 | 600/1500 | 300/1000 | 10D/20D |
| GYTS-8~12X | 8~12 | 2 | 9.5 | 100 | 600/1500 | 300/1000 | 10D/20D |
| GYTS-14~18X | 14~18 | 3 | 9.5 | 100 | 600/1500 | 300/1000 | 10D/20D |
| GYTS-20~24X | 20~24 | 4 | 9.5 | 100 | 600/1500 | 300/1000 | 10D/20D |
| GYTS-26~30X | 26~30 | 5 | 9.5 | 100 | 600/1500 | 300/1000 | 10D/20D |
| GYTS-32~36X | 32~36 | 6 | 10 | 119 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-38~48X | 38~48 | 4 | 11 | 136 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-50~60X | 50~60 | 5 | 11 | 136 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-62~72X | 62~72 | 6 | 12 | 155 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-74~84X | 74~84 | 7 | 13.6 | 192 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-86~96X | 86~96 | 8 | 13.6 | 192 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-98~108X |
98~10 8 |
9 | 15 | 227 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-110~120X | 110~120 | 10 | 15 | 227 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-122~132X | 122~132 | 11 | 16.9 | 227 | 1000/3000 | 300/1000 | 10D/20D |
| GYTS-134~144X | 134~144 | 12 | 16.9 | 227 | 1000/3000 | 300/1000 | 10D/20D |
1, Free samples--- we can supply free products for testing .
2, Brand---OEM service acceptable
3, Payment terms---Nice payment. Like T/T, Western Union, Paypal etc.
4, Quality Level---High quality as per your requirements.
5, Competitive price---The manufacturer having our own factory has the advantage.
6, Delivery Time--- Usually 3 days. Less than a week.
8, Optical Network Project Consultant---Professional experts help you.
9, New Products development for customer---We can produce it for you with pattern.
10, logistic solution--- Cost-effective ways can be chosen for you.
OMC industry co., limited, which was founded by an expert team, has been exporting FTTX passive products since 2007. We focus on providing innovative and integrated FTTX solutions for a variety of applications/Networks. Our capabilities include product/solution design, development, enhancement and integration. Our products are among the highest performing in the industry and truly represent the best values in the industry. We also offer training, pre and post-sales support. We help you select the right products for your Optical network’s needs.
Quality is life of OMC. Our firm commitment is to deliver world class product to our customers and forever exceed their expectations. We also offer Solid after sales support i.e. 3 years product warranty under no conditions
OMC treat our customers, suppliers, and employees as our respectable partners. We very happy to share our success with them. Offering best products to our customers, Long-term/Loyal partnership to our supplier and good salary/welfare to our employees. OMC also spare no effort to care our society and environment. With a grateful heart, OMC will go firmly to the bright way that we are longing for.
We hereby gather in OMC, with plentiful passion and professional techniques to service customers all over the world
