Floor Tile Gportable Gloss Meter Auto Calibration YG60S 200gu AA Battery
Beijing floor tile gloss meter with auto calibration YG60S 200gu AA battery
YG60S 60°Economic Gloss Meter is independently developed by Silk with independent intellectual property, manufactured according to international standard ISO2813 and China standard GB/T 9754. With auto-calibration and high-end QC software, it can meet the second grade requirements of JJG696.
YG60S 60° Economic Gloss Meter can test material with gloss (0-200Gu), and universally apply to paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc. for gloss measurement and gloss data transmission.
Product Features:
1. Elegant Design combined with aesthetics and ergonomics;
2. With auto-calibration function;
3. Meet the second grade requirements of JJG696;
4. Auto Power-off within optional 30-120 seconds;
5. Comply to ISO2813,ASTM523, GB/T9754;Product Features:
Application:
Widely used in the filed of paints,coating,plastics,ink,rubber,printing,paper, glass, handware, ceramic, marble etc.
Specification:
| Model | YG60S Economic gloss meter |
| Measuring Angle | 60° |
| Measuring Area | 60°:9X15 |
| Measuring Range | 60°: 0~200GU |
| Division Value | 1GU |
| Measuring Modes | Basic mode |
| Measuring Time | 0.5S |
| Repeatability | 0~100GU:±0.5GU ; 100~200GU:±0.5%GU |
| Accurate | Conform with JJG696 second grade requirements of gloss meter |
| Auto Power-off Time | 30s |
| Long-time Calibration | no |
| Language | Chinese & English |
| Storage | no |
| Display | 2.3 inch white and black screen |
| Size | 160*52*84mm |
| Weight | About 300g |
| Power Supply | 1pc dry-cell battery(can measure 10000 times) or use USB Charge |
| Interface | no |
| PC Software | no |
| Operation Temperature Range | 0-40℃(32-104° F) |
| Storage Temperature Range | (-20-50℃)(-4-122° F) |
| Humidity Range | < 85% RH, without condensation |
| Standard Accessories | User manual, calibration plate |
| Optional Accessories | Miniature printer |
| Notification: the technical parameter is only for reference | |
