Mufflers Pipe Double Braided Stainless Steel Flex Exhaust Bellows Long Life
Mufflers Pipe Double Braided Stainless Steel Flex Exhaust Bellows
Introduction:
A flex pipe is flexible piece of pipe that allows the exhaust system some flexibility. Flex pipes are an essential part of any front wheel drive vehicle and on most all wheel drive vehicles. On front wheel cars, since the motor is mounted transversely, when you accelerate the motor rocks and the flex pipe protects your exhaust system from breakage. Without that extra flex the rocking motion would crack the exhaust system causing a loud leak.
Types:
1, outer braided + bellow
2, outer braided + bellow + inner braided
3, outer braided + bellow + interlock
4, outer wire mesh + bellow
5, outer wire mesh + bellow + interlock
6, outer braided + bellow + nipple
(Size, diameter and length can be produced as client's requirements)
Stainless Steel Flex Exhaust Bellows Specifications:
| Inner Diameter (ID) | Length(L) | Inner Diameter (ID) | Length(L) |
| 1-3/4” (45mm) | 4”(102mm) | 3”(76.2mm) | 4”(102mm) |
| 6”(152mm) | 6”(152mm) | ||
| 7”(178mm) | 8”(203mm) | ||
| 8”(203mm) | 10”(254mm) | ||
| 9”(230mm) | 12”(305mm) | ||
| 10”(254mm) | 42mm | 120mm | |
| 11”(280mm) | 165mm | ||
| 12”(305mm) | 180mm | ||
| 2”(50.8mm) | 4”(102mm) | 50mm | 120mm |
| 6”(152mm) | 165mm | ||
| 7”(178mm) | 55mm | 120mm | |
| 8”(203mm) | 165mm | ||
| 9”(230mm) | 180mm | ||
| 10”(254mm) | 200mm | ||
| 11”(280mm) | 250mm | ||
| 12”(305mm) | 60mm | 160mm | |
| 2-1/4”(57.2mm) | 4”(102mm) | 200mm | |
| 6”(152mm) | 240mm | ||
| 7”(178mm) | 65mm | 150mm | |
| 8”(203mm) | 200mm | ||
| 9”(230mm) | 70mm | 100mm | |
| 10”(254mm) | 120mm | ||
| 11”(280mm) | 150mm | ||
| 12”(305mm) | 200mm | ||
| 2-1/2”(63.5mm) | 4”(102mm) | Note: Customized size are available. | |
| 6”(152mm) | |||
| 7”(178mm) | |||
| 8”(203mm) | |||
| 9”(230mm) | |||
| 10”(254mm) | |||
| 11”(280mm) | |||
| 12”(305mm) | |||
