Two Stations Motor Winding Testing Equipment For Food Milling Machine
Price:
Negotiable
MOQ:
1 set
Delivery Time:
45 working days
Brand:
AIP
Product Description
Food Milling Machine Motor Testing Machine, Motor Testing System
1. Test object: food milling machine motor
2. Motor picture
3. Technical parameters
| Direction of rotation | |
| rotation | CW, CCW, still |
| Surge | |
| output voltage setting range/precision | 500～3000V ±(3%×display value+8V) |
| sampling frequency | 100MHz |
| waveform comparison |
area, area difference, corona and phase 3 waveforms displayed in the testing interface |
| AC Hipot | |
| test time range/resolution | 0.5～999.9s 0.1s/step |
| Output voltage setting range and precision | AC 200～3000V ±(2%×setting value+10V) |
| breakdown current testing range/precision | 0.10～20.00mA ±(2%×display value+0.05 mA) |
| Hipot current presetting alarm range | Max:0.10～20.00mA；Min:0.00～20.00mA |
| Insulation resistance | |
| output voltage setting range/precision | DC 500V/1000V ±(2%×setting value+10V) |
| insulation resistance testing range/precision |
1～500MΩ ≤100MΩ:±(3%×setting value+0.5MΩ) ；>100 MΩ:±(5%×setting value+5MΩ) |
| insulation resistance alarm setting range | Max: 0～500MΩ; Min: 1～500MΩ |
| test time range/resolution | 0.5～999s 0.1s/step |
| DC winding resistance test | |
| testing range and precision | 10.0mΩ～20KΩ ±(0.3%×display value+3 words) temperature compensation can be set. |
| test time range/resolution |
0.5～999s 0.1s/step
|
| temperature compensation function | Yes |
| temperature probe/range | DS18b20 -10.0℃~+50.0℃ |
| precision | ±0.5°C(range: -10℃~+50℃) |
| No-load | |
| voltage testing range and precision | AC:30～500V ±(0.5%×display value+1 word) |
| current testing range and precision | AC:0.02～5.0A ±(0.5%×display value+2 words) |
| power testing range and precision | 0.6-1500W ±(0.5%×display value+5 words) |
| Stall | |
| voltage testing range and precision | AC:30～500V ±(0.5%×display value+1 word) |
| current testing range and precision | AC:0.02～5.0A ±(0.5%×display value+2 words) |
| power testing range and precision | 0.6-1500W ±(0.5%×display value+5 words) |
| Low voltage start | |
| voltage testing range and precision | AC:30～500V ±(0.5%×display value+1 words) |
| current testing range and precision | AC:0.02～5.0A ±(0.5%×display value+2 words) |
| power testing range and precision | 0.6-1500W ±(0.5%×display value+5 words) |
4. Service
4.1 Modular design makes the maintenance easier
4.2 Remote control failure diagnosis
4.3 The motor testing machine diagnose itself automatically when switch on and the failure module can be positioned precisely.
5. Training
