450000 Kcal/H Thermal Heat Husk Furnace With Automatic Feeding Device
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
15 working days
Brand:
ZENVO
Product Description
450,000 Kcal/H Thermal Heat Husk Furnace With Automatic Feeding Device
450,000 Kcal/h thermal heat Biomass Furnace for 30 ton per batch dryer
Features:
Indirect heating, the clean air won't contaminate grain, with new heat exchage technology, the exchage rate can be 80%.
The fuel could be paddy husk, fire wood, straw, coal etc. the drying expense is very low.
Equipped with automatic husk feeder, reduce manual operation.
Automatic temperature controlling, temeparture difference is only 1 degree.
Technical Parameters:
| Model | 5L-45 | 5L-55 | 5L-80 |
| Rated Thermal Energy (Kcal/h) | <450,000 | <550,000 | <800,000 |
| Output hot air temperature | <120 ℃ | ||
| Voltage | Three Phase 380V /440V | ||
| Ignition | Manual | ||
| Heat Supply Method | Indirect hot air supply, auto temperature control | ||
| Total Motor Power | 2.57 kW | 2.87 kW | 3.85 kW |
| Fuel | Coal, Firewood, Paddy Husk, Straw etc. | ||
| Feeding Method | Manual / Auto Feeding (option only for husk) | ||
| Rated Energy Consumption | Paddy husk: 65~160 | Paddy husk: 75~180 | Paddy husk: 135~250 |
| Overall Dimension (L*W*H) | 3110*1500*1920mm | 3110*1500*2250mm | 4200*1800*2550mm |
| Weight | 4560 KGS | 4700 KGS | 9630 KGS |
| Quantity of Dryers | 3 sets 15 ton | 3~4 sets 15 ton | 5 sets 15 ton |
*Specification is subject to change without notice
*The parameters are just for reference.
