Split Sleeve Polymer Nylon Grooved Drum Device Machine
Split Sleeve Polymer Nylon Grooved Drum Device Machine
Products Lookview:
| Rope diameter | 3-99mm |
| Rope capactity | 20-1000M |
| Most load capacity | 50MT |
| Sling type | Wire or Cable |
| Speed | 0-20m/min |
| Application | Drilling rig,Mining,Machine ,Mooring,Construction, Hoisting, |
| Product working arts |
CNC machining center |
Technical parameters and application:
| No: | Wire diameter(mm): | Rotation direction | Main drum diameter(mm) |
Main drum length(mm) | Application |
| 1 | 8 10 13 | Lefthand,Righthand | 430 | 763 | The oil workover rig winch,Towing winchTower crane |
| 2 | 13 15 18 | Lefthand,Righthand | 623 | 1144 | Engineering winch, Lifting winch,Crawler crane |
| 3 | 22 25 26 | Lefthand,Righthand | 730 | 1220 | Oil workover rig , Logging Winch |
| 4 | 18 22 32 | Lefthand,Righthand | 670 | 1240 | Drilling Rig Winch, drawworks |
| 5 | 28 32 36 40 | Lefthand,Righthand | 560 | 630 | Rotating Drilling Rig winch, Lifting equipment |
| 6 | 26 28 32 45 | Lefthand,Righthand | 760 1146 | 1970 1765 | Offshore Crane, Marine crane,Mooring winch |
The most important parameter for produce the drum:
1) Wire rope or cable diameter (mm)
2) The main drum diameter (mm)
3) Width between flanges (mm)
4) Length of rope or cable to be accommodated
5) Material and requirements of the drum
6) Maximum operating load on rope or cable
7) Direction of wire rope entry
8) Type of rope entry
9) Distance to fixed sheave and position between flanges
10) Outside diameter of flanges
Product advantage:
LBS Grooved drum, solved the problem of bitten rope in wire rope winding process. LBS groove
system makes the winding of wire rope smooth, and the load of each layer evenly
