High Efficient Tower Crane Engineering Wire Rope Winch Drum Single Drum

High Efficient Tower Crane Engineering Wire Rope Winch Drum Single Drum

Product lookview:

Rotation Direction: Left or Right(as require)

Wire Rope Diameter: 3 MM~190 MM

Wire capacity:100-10000M

Processing equipment: CNC machining center

Durm Type: Spooling system - based on the unique geometry of the drum grooving

Service: All of the product be customized

Technical Parameters: (All of the parameter should be according to each product)

Processing equipment: CNC machining center

Rotation Direction: Left or Right

Wire Rope Diameter: 3 MM~190 MM

Product condition:New to order

Why you shoud choose us:

1)10 years design and produce experience

2) patent award by government

3)The specilized in design and drawing for one of the customer according the different usage

4)The successful case with China big government project

5) Top quality with competitive price.

Products Drum Feature

1. Compact structure and reasonable design

2. Safe and reliable function

3. Highly efficient, constant operating torque motor.

4. Smooth running over the entire speed range.

Product Material:

Carbon steel, alloy steel, cast steel, aluminum, all kinds of high-strength steel Q345, Q420, Q460, 15CrMo,20GrMo, 42GrMo, etc

Material standards: GB, AISI, ASME, ASTM, JIS DIN, NF, BS, EN ...

Classification societies certified: DNV, ABS, GL, LR, BV, CCS, RINA, NK, KR ...

Product Application:

1. Crane machinery: The bridge lifting machine, Tower crane, Gantry crane,Crawler crane winch
2. The petroleum industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , Logging winch, etc
3. Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
4. The construction machinery: Building wipe wall winch, Winding hoist, Windlass
5. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
6. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc

Product Material:

Alloy steel, cast steel, aluminum, all kinds of high-strength steel Q345,Q420,Q460,15CrMo,20GrMo, 40GrMo, 42GrMo...

Material standards: GB, AISI, ASME, ASTM, JIS DIN, NF, BS, EN ...

Classification societies certified: DNV, ABS, GL, LR, BV, CCS, RINA, NK, KR ...

Product Structure:

Integral rope groove drum: rope drums with grooves cut directly into them (with or without bolted or welded flanges, as required).Winch drum with flange, the LBS groove is cut directly into the body of the drum, according to customers’ requirements, the flanges are either welded or screw-bolted. groove geometry is determined by rope construction, diameter and length, and by application. the drum has the required mounting dimensions for the actual operating conditions.

Important News to Buyer:

If you using the snooth drum winch ,then you will face the problem that you want to chage the rope type or the capacity or some usage working function like that ,now you only want to change the  groove sleeve installing on the smooth drum instead of to chage the whole winch .That is convinent and save the time and money for you .If you get the knowledge?
