391629 Rechargeable Lithium Polymer Battery 3.7V 160mAh Lipo Battery 5.0g Weight
Rechargeable Polymer 391629 Prismatic Lithium Ion Battery 3.7V 160mAh
LITHIUM ION BATTERY GENERAL INFORMATION
Lithium ion batteries (Li-Ion polymer) are high energy density battery that are widely used in from the electric equipment to electronics devices market. Pknergy Battery manufactures lithium ion batteries and li-polymer batteries with mainly three type of chemical raw materials for different applications. These three types chemical materials are LiCoO2, NMC and LiFePO4 used for anode electrode. Commonly LiCoO2 batteries are used for portable consumer electronics because of its highest energy density in three, like smartphones, medial players, table PC, while NMC and LiFePO4 lithium ion batteries are used for applications that requires rugged operating environment, long cycle life, high output current, such as power tools, solar energy storage, UPS , E-bikes, etc.
Polymer Lithium Battery Key Features
Environmental Friendly Chemistry
High Energy Density
High Power Density
Fast Charge Capability
Excellent Cycle Life
Can customize Dimension, Capacity, Discharge Current and more.
391629 Rechargeable Polymer Battery Data Sheet
| Rating | Note | |||||
| 3.1 Capacity | 160mAh | Discharge:0.2CmA (32mA)cut off Voltage:3.0V for cell | ||||
| 3.2 Nominal Voltage | 3.7V | |||||
| 3.3 AC Impedance Resistance | ≤320mΩ | |||||
| 3.4 Discharge Cut-off Voltage | 3.0V | |||||
| 3.5 Charge Voltage | 4.2V | |||||
| 3.6 Max. Charge Voltage | 4.25V | |||||
| 3.7 Max. Charge Current | 160mAh | 1.0C | ||||
| 3.8 Max. Discharge Current | 160mAh | 1.0C | ||||
| 3.9 Weight | Approx 5.0g | |||||
| 3.10 Operating Temperature | Charge | 0~45°C | ||||
| Discharge | -20~60°C | |||||
| 3.11 Storage Temperature | <1months | -5~45°C | Recommended storage temperature: 23°C,at the shipment state | |||
| > 6 months | 0~35°C | |||||
