2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
Price:
Negotiation
MOQ:
1 set of topkit tower crane
Delivery Time:
about 25 days after receiving the deposit
Brand:
HYCM TOWER CRANES
Product Description
2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
Quick Details for 2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
- This tower crane is an hammerhead with topkit head tower crane, includes foundation frame, mast sections (tower body), climbing system, slewing units, horizontal lifting jib / boom, counter-jib, tower head, operation cab, three mechanisms, electric system and safety device.
- The max. Boom length is 56m which consist of every 6meters and minimum length is 30m
- This tower crane freestanding height is 40m and max.height is 150m with more mast section and 5sets anchorages.
- The max. Load capacity is 6t and tip load at the end jib is 1.0t.
Specifications for 2020 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
| Main Performance | Main Specifications | |
| Rated lifting moment (KN.m) | 800 | |
| Max. lifting load(t) | 6 | |
| Tip load(t) | 1.2 | |
| Working range(m) | 56 | |
| Lifting height(m) | Freestanding height | 40 |
| Attaching height | 150 | |
| Mast section | Main limb (mm) | 135×12 Square tube/ Q345B |
| Section size(mm) | 1600×1600×2500 | |
| Lifting jib | Upper chord(mm) | Ø89×8 / 20# |
| Lower chord(mm) | 100×8 Square tube / Q345B | |
| Parallel face width (mm) | 1360 | |
| Counter jib | Main limb(mm) | ［32b/ Q235B |
| Length(m) | 12.636 | |
| Hoisting mechanism | Reducer | 24TQL15 |
| Motor | YZTD200L-2/4/16p-24/24/5.4KW | |
| Brake | YZW3H-200/45 | |
| Wire rope | 6×37-13-1770-1-1 right lay | |
| Hoisting speed (m/min) | 80/40/8.5 40/20/4.25 | |
| Slewing mechanism | Reducer | XX80.195 (double) |
| Motor | YZR132M1-6-3.7KW×2 (double) | |
| Coupler | YOX250A×2 | |
| Slewing speed (r/min) | 0.6 | |
| Trolleying mechanism | Reducer | BE3358X |
| Motor | YDEJ132S-4/8-3.3/2.2KW | |
| Trolleying speed( m/min) | 40/20 | |
| Jacking-up speed |
Hydraulic pump station Jacking oil cylinder |
TQZ80/160/125 |
| Motor | Y132M-7.5 | |
| Slewing bearing | Type | 1250.40 |
FAQ for 2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
Q1: What is the Warranty for tower cranes?
A1: For the tower cranes, we can supply 1 year warranty. If there is quality problem of any parts (excluding easy worn spare parts) on our side during this period, we will supply a new one by free for replacement
Q2: How many countries had your tower cranes exported to?
A2: Our tower cranes had exported to more than 30 countries, such as Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia, Russia, Kazakhstan, Brazil, Cyprus, Belgium, Madagascar, Thailand and Algeria etc.
Q3: What is your trade items of Tower Crane?
Qingdao or Shanghai or according to Clients' need. We could accept 1 set of our products as your trial order.
We will try our best to help you find the most suitable product!
"6S" SERVICES for 2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
Smart 1- Collaborate with others to solve your entire problem
Smart 2- Our goal is to provide you with a personalized service and complete solution
Specialized 1- Strict raw material control, only the best will pass the test
Specialized 2-Strict quality control, making flawless finished products
Speedy 1- Professional sales team, guarantee reply with-in 12 hours
Speedy 2- Speedy dispatch with minimal delays
Study 1—Study traditional Chinese values. Educating to be better person first, making better products after that
Study 2-Educate ourselves with professional for better service
Support 1-We have skilled expert providing all technical support
Support 2-Our front line workers are united and skilled
Sincere1- Think from our customers' perspective and fulfill their needs with our best effort.
Sincere 2-A warm welcome for every customer, build genuine relationships from friends all over the Globle.
Photos for 2024 Hot Factory Direct Sale 6ton Load 56m Boom Hammerhead Tower Crane Manufacturer
