Indoor HD GOB LED Panel P1.25 with Ultra-thin 33mm Cabinet Front Access Service and High-Definition Display
Price:
Negotiable
MOQ:
10sqm
Delivery Time:
15 working days
Brand:
TBC LED
Product Description
Indoor HD GOB LED Panel with Ultra-thin 33mm Cabinet Front Access Service and High-Definition Display
High-definition indoor LED panel featuring ultra-thin 33mm cabinet design with hardwired connection, ideal for professional indoor display applications.
Specifications
| Model | P1.25 | P1.56 | P1.95 | P2.5 | P2.604 | P2.976 | P3.91 |
|---|---|---|---|---|---|---|---|
| LED type | SMD1010(GOB) | SMD1212(GOB) | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD2121 |
| Physical density(dots/sq.m) | 640000 | 409600 | 262144 | 160000 | 147456 | 112896 | 65536 |
| Module resolution | 200×200 | 160×160 | 128×128 | 100×100 | 96×96 | 84×84 | 64×64 |
| Module dimension(mm) | 250×250 | 250×250 | 250×250 | 250×250 | 250×250 | 250×250 | 250×250 |
| Panel resolution | 800×400/800×200 | 640×160/480×160 | 512×128 | 400×100 | 384×96 | 336×84 | 256×64 |
| Maintenance | Front access service | ||||||
| Cabinet material | Die-Cast Aluminum | ||||||
| Pixel calibration | Yes | ||||||
| Brightness(cd/m²) | 600 | 600 | 800 | 800 | 800 | 800 | 1000 |
| Color temperature(K) | 3200-9300 Optional | ||||||
| Grey scale(bit) | 14/16 Optional | ||||||
| Viewing angle(V/H) | 160°/160° | ||||||
| Brightness/Color uniformity | ≥97% | ||||||
| Contrast | 5000:1 | ||||||
| Frequency rate | 50/60 | ||||||
| Drive mode | 1/50Scan | 1/40 Scan | 1/32 Scan | 1/25 Scan | 1/32 Scan | 1/28 Scan | 1/16 Scan |
| Max power consumption(w/m²) | 650 | 650 | 650 | 650 | 650 | 660 | 650 |
| Avg. power consumption(w/m²) | 100-200 | ||||||
| Protection level | IP31 | ||||||
| Working temperature and humidity | -20~60°C/10%-85% | ||||||
| Storage temperature and humidity | -20~60°C/10%-85% | ||||||
| Warranty | 2 years | ||||||
Key Advantages
- Easy Installation & Maintenance: Front maintenance design, magnetic modules, and integrated quick-connect ports (power/signal) cut wiring and setup time.
- Precision Aluminum Cabinet: One-piece die-cast aluminum build ensures stability and fast assembly.
- Ultra-Thin & Stylish: Only 33mm thick, with a sleek look that fits various indoor decors.
- Flexible Shaping: Supports flat, right-angle, and cylindrical configurations for creative setups.
- Top-Tier Image Quality: 16-bit grayscale, 10000:1 contrast, high brightness, and vivid colors for clear visuals.
- Dual-sided display available: Supports synchronous or asynchronous screen content.
Product Highlights
- Front Maintenance Design: Simple structure for easy installation.
- Integrally Formed High-Precision Die-Cast Aluminum Cabinet: Enables quick assembly.
- Sleek & Minimalist Appearance: Ultra-thin design for aesthetic appeal.
- Flexible Splicing: Supports right-angle, cylindrical, and other custom shapes.
- Superior Image Quality: Clear picture with high brightness, high contrast, and excellent color saturation.
