Schurter SPT Equivalent PCB Or THT Mounting 3.6x10mm Slow Blow Cartridge Ceramic Tube Fuse 125V 100mA-12A
Schurter SPT Equivalent PCB Or THT Mounting 3.6x10mm Slow Blow Cartridge Ceramic Tube Fuse 125V 100mA-12A
Applications
Primary circuit protection:
a. Power supplies
b. LED and general lighting
c. Consumer electronics
d. Desktop, laptop and notebook
e.Test equipment
______________________________________________________________________________
Download________
Product description
I Time-delay (Slow blow )
II Designed to IEC60127-3
III Nickel-plated brass single end cap construction
IV 3.6 mm x 10 mm compact design utilizes less board space
V Halogen free, lead free, RoHS compliant
| Ao littel Ceramic Tube Fuse Family Member | ||||
| No. | Size | Blow | Voltage | Series |
| 1 | 3.6x10mm | Slow Blow | 125V/250V | PTU |
| 2 | 3.6x10mm | Fast Blow | 125V/250V | PTU |
| 3 | 4x11mm | Slow Blow | 125V/250V | HTP |
| 4 | 4x11mm | Fast Blow | 125V/250V | HFP |
| 5 | 5x20mm | Slow Blow | 125V/250V | BTC |
| 6 | 5x20mm | Fast Blow | 125V/250V | BFC |
| 7 | 6.32x32mm | Slow Blow | 125V/250V | BMT |
| 8 | 6.32x32mm | Fast Blow | 125V/250V | BMF |
Specification (A = 250V/ B =125V,● Approved / ○ Pending)
|
Part No. |
Ampere Rating |
Voltage Rating |
Breaking Capacity |
I2TMelting Integral(A2.S) |
Agency Approvals |
||
| UL | CUL |
PSE
|
|||||
| PTU0100A/B | 100mA | 250V/125V | 50A@125V/250VAC | 0.0042 | ○ | ○ | ○ |
| PTU0125A/B | 125mA | 250V/125V | 50A@125V/250VAC | 0.010 | ○ | ○ | ○ |
| PTU0160A/B | 160mA | 250V/125V | 50A@125V/250VAC | 0.025 | ○ | ○ | ○ |
| PTU0200A/B | 200mA | 250V/125V | 50A@125V/250VAC | 0.035 | ○ | ○ | ○ |
| PTU0250A/B | 250mA | 250V/125V | 50A@125V/250VAC | 0.056 | ● | ● | ○ |
| PTU0300A/B | 300mA | 250V/125V | 50A@125V/250VAC | 0.10 | ● | ● | ○ |
| PTU0315A/B | 315mA | 250V/125V | 50A@125V/250VAC | 0.12 | ● | ● | ○ |
| PTU0350A/B | 350mA | 250V/125V | 50A@125V/250VAC | 0.15 | ● | ● | ○ |
| PTU0400A/B | 400mA | 250V/125V | 50A@125V/250VAC | 0.25 | ● | ● | ○ |
| PTU0500A/B | 500mA | 250V/125V | 50A@125V/250VAC | 0.35 | ● | ● | ○ |
| PTU0630A/B | 630mA | 250V/125V | 50A@125V/250VAC | 0.55 | ● | ● | ○ |
| PTU0750A/B | 750mA | 250V/125V | 50A@125V/250VAC | 0.70 | ● | ● | ○ |
| PTU0800A/B | 800mA | 250V/125V | 50A@125V/250VAC | 1.1 | ● | ● | ○ |
| PTU1100A/B | 1A | 250V/125V | 50A@125V/250VAC | 2 | ● | ● | ○ |
| PTU1125A/B | 1.25A | 250V/125V | 50A@125V/250VAC | 3.8 | ● | ● | ○ |
| PTU1150A/B | 1.5A | 250V/125V | 50A@125V/250VAC | 4.2 | ● | ● | ○ |
| PTU1160A/B | 1.6A | 250V/125V | 50A@125V/250VAC | 6.2 | ● | ● | ○ |
| PTU1200A/B | 2A | 250V/125V | 50A@125V/250VAC | 13 | ● | ● | ○ |
| PTU1250A/B | 2.5A | 250V/125V | 50A@125V/250VAC | 18 | ● | ● | ○ |
| PTU1300A/B | 3A | 250V/125V | 50A@125V/250VAC | 28 | ● | ● | ○ |
| PTU1315A/B | 3.15A | 250V/125V | 50A@125V/250VAC | 32 | ● | ● | ○ |
| PTU1350A/B | 3.5A | 250V/125V | 50A@125V/250VAC | 39 | ● | ● | ○ |
| PTU1400A/B | 4A | 250V/125V | 50A@125V/250VAC | 43 | ● | ● | ○ |
| PTU1500A/B | 5A | 250V/125V | 50A@125V/250VAC | 50 | ● | ● | ○ |
| PTU1600A/B | 6A | 250V/125V | 50A@125V/250VAC | 56 | ○ | ○ | ○ |
| PTU1630A/B | 6.3A | 250V/125V | 50A@125V/250VAC | 60 | ○ | ○ | ○ |
| PTU1700A/B | 7A | 250V/125V | 50A@125V/250VAC | 65 | ○ | ○ | ○ |
| PTU1800A/B | 8A | 250V/125V | 50A@125V/250VAC | 70 | ○ | ○ | ○ |
| PTU2100A/B | 10A | 250V/125V | 50A@125V/250VAC | 78 | ○ | ○ | ○ |
| PTU2100A/B | 12A | 250V/125V | 50A@125V/250VAC | 80 | ○ | ○ | ○ |
Product Characteristics
| Material | Body: Ceramic Cap: Nickel Plated Brass Tin Plated Copper |
| Terminal Strength | MIL-STD-202, Method 211, Test Condition A |
| Solderability | MIL-STD-202, Method 208 |
| Product Marketing | Body: Brand Logo, Current Rating ,Voltage Rating, Agency approval marks |
| Packaging | Bulk (500 pcs/polybag,5000pcs/box,20000pcs/carton) |
| Operating Temperature | -55ºC to 125ºC |
| Thermal Shock | MIL-STD-202, Method 107 Test Condition B3 (5 cycles -65ºC to +125ºC) |
| Vibration | MIL-STD-202, Method 201 (10-55 Hz) |
| Humidty | MIL-STD-202, Method 106, High Humidity (90-98%RH), Heat (65ºC) |
| Salt Spray | MIL-STD-202, Method 101, Test Condition B |
Operating Characteristics
|
% of Ampere Rating(In) |
Blowing Time |
| 100% * In | 4 hours Min |
| 200% * In | 60 sec Max |
Packaging Datas
| Bulk | ||
| Bulk 500 pcs in per poly bag |  |
|
| 10 poly bags in per inner box |  |
L240±2 * W170±2 * H110±2 |
| 4 inner boxes in per outer carton |  |
L390±5 * W240±5 * H250±5 |
