Shield Screening VLT 73% Yag 1064nm Laser Safety Window
Price:
Negotiated
MOQ:
10pcs
Delivery Time:
5-8 work days
Brand:
xinland
Product Description
YAG 1064nm Laser Shield Screening Working Place Laser Window
Protection Wavelength: 190~450nm, 800~1100nm, OD6+
Typical:980nm,1064nm, 1070nm
VLT:55%
FEATURES:
Mainly for Infrared 1064nm,1070nm with high optical density of ,6+,8+.
APPLICATION:
Safety window for laser processing equipment.
YAG laser 1064nm, fiber laser 1070nm and 1080nm.
For example, Laser engraving, Laser cutting.
Catalog of YAG 1064nm Laser Shield Screening Working Place Laser Window
| Series NO. | Protection Wavelength | Dimension(mm) | OD | vlt |
| XL1PW5D5T | 190~550nm | 1280*1000*5mm | 5+ | 15% |
| XL2PW4D5T | 580nm~750nm | 1280*1000*5mm | 5+ | 40% |
| XL3PW4D5T | 800~1100nm | 1280*1000*5mm | 4+ | 73% |
| XL3PW6D5T | 800~1100nm | 1280*1000*5mm | 6+ | 60% |
| XL3PW8D5T | 800~1100NM | 1280*1000*5mm | 8+ | 42% |
| XL3PW4GD5T | 190~540nm & 800~1100nm | 1280*1000*5mm | 4+ | 25% |
| XL4PW4D5T | 190~450nm & 800~1700nm | 1280*1000*5mm | 4+ | 35% |
| XL5PW4D5T | 190~420nm & 860~1300nm | 1280*1000*5mm | 4+ | 28% |
| XL6PW4D3T | 1064nm&10600nm | 1200*1000*3.3mm | 4+ | 40% |
| XL6PW5D5T | 1064nm&10600nm | 1200*1000*5mm | 5+ | 40% |
| XL6PW6D5T | 1064nm&10600nm | 1200*1000*5mm | 6+ | 30% |
| XL7PW4D5T | 10600nm | 1200*1000*5mm | 6+ | 90% |
| XL8PW4D6T | 860-960nm ,960-2000nm,1050-1760nm | 1200*1000*5mm | 6+ | 53% |
