Vertical Gas Filling Insulating Glass Production Line Automatic 2000 Mm Height

LJBZ IG line uses advanced technology to make high-quality and variety DGU automatically, such as double glass, triple glass, shaped glass and stepped glass. Double glazed glass production line consists of four sections, transfer section, washing section, inspection section and pressing section. It uses advanced technology to make high-quality and variety DGU automatically, such as double glass, triple glass, shaped glass and stepped glass.

Machines features:

1. Vertical-glass glazed washing and drying machine with high automatic level is fully controlled by PLC system,the operation is easy and humanized

2. Touch screen operation interface.It is easy to transfer between automation and hand-operation

3. Self diagnosis system brings much high convenience to the user

4. Automatically distinguish the film of LOW-E and coated glass

5. Vertical-glass glazed washing and drying machine washing part is completely made of stainless steel,

tempered glass door makes the operation inside clearly monitored, Signal switch on the top of the door avoid possible injure to the operater

6. Energy saving and interrupted system for the washing machine

7.Unique water nozzle design makes the maintenance easy and fast

8.Heating system for the water and blowing air. Start it when the ambient temperature no more than 7 degree

9.Automatic control 6 brushers for Glass

10. Vertical-glass glazed washing and drying machine There is special system for Producing triple insulating glass

11. Having system for wrong operation and automatically wait the second glass following.

12. Automatic assembly inside the press machine

13.High class casting and processing of spare parts assure good stability of the line

14.The key connections use expanded joint in stead of common union.This guarantee high adjustment precision and conveying reliability
