Six Servos Glass Production Line , Film Glass Edge Deletion Two Way Access
Six Servos Glass Production Line 30 M/Min , Film Glass Edge Deletion Two Way Access
Automatic low-e glass edge deletion machine adopts Germany siemens brand spare parts, cooperating with Bystronic technology to develop the smart machine.
Technical data
| Max.glass processing size | 2500*4500mm |
| Min.glass processing size | 350*500mm |
| Glass thickness | 3-19mm |
| Edge deleting width | 10-50mm |
| Glass conveyor speed: | 30m/min |
| Edge deleting speed | 0-15m/min |
| Abrasive wheel width | 10/12/15mm |
| Air supply | Flow 0.2m3/min |
| Air pressure | ≥0.8MPa |
| Total power | 3P 380V 50Hz 3.35KW |
| Dimension | 8000*2500*3400mm |
Main feature
- PLC control system,touch screen interface
- Six servos control system
- Intelligent control system, can recognize batch processing
- Two-way glass access
- Automatically measure size
- Automatically distinguish low-e surface
- Edge deletion is adjustable
- Safe and full automatic device
Introduce :
1. Application : Insulated glass processing machine
2. Production name : Smart vertical glass edge deletion machine
3. Max glass size: 2500*4500mm
4. Min glass size : 400*400mm
5. Edge deleting speed : 2-29m/min
6. Total power : 3P 380V 50Hz 3.35KW
7. Glass thickness : 3 - 15mm
8. Place of origin : Jinan city, China
9. Brand name : LIJIANG GLASS
10. Using : Deleting low-e glass edge
