C30 STEEL FLANGE C50 forged flanges c60 Steel forged Flanges C25E Forged Steel flanges C35E Forged flange
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
C30 STEEL FLANGE C50 forged flanges c60 Steel forged Flanges C25E Forged Steel flanges C35E Forged flange
| Grade : | C25E | |
| Number: | 1.1158 | |
| Classification: | Steel | |
| Standard: |
|
| C | Si | Mn | Ni | P | S | Cr | Mo | - |
| 0.22 - 0.29 | max 0.4 | 0.4 - 0.7 | max 0.4 | max 0.035 | max 0.035 | max 0.4 | max 0.1 | Cr+Mo+Ni < 0.63 |
Mechanical properties of steel C25E (1.1158)
| Nominal thickness (mm): | to 100 | 100 - 250 | 250 - 500 | 500 - 1000 |
| Rm - Tensile strength (MPa) (+N) | 440 | 420 | 400 | 390 |
| Nominal thickness(mm): | to 100 | 100 - 250 | 250 - 500 | 500 - 1000 |
| Re - Upper yield strength (MPa) (+N) | 230 | 210 | 190 | 180 |
| Nominal thickness (mm): | to 100 | 100 - 250 | 250 - 500 | 500 - 1000 |
| A - Min. elongation at fracture (%) longitud., (+N) | 23 | 23 | 23 | 22 |
| A - Min. elongation at fracture (%) transverse, (+N) | 17 |
| EU EN |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Russia GOST |
Inter ISO |
||||||
| C25E |
|
|
|
|
|
|
