1.0576 welding neck flanges S355J2H wn neck flanges exported fine grain steels forged flanges
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
| Grade : | S355J2H | ||
| Number: | 1.0576 | ||
| Classification: | Non-alloy structural steel | ||
| Standard: |
|
| Method of deoxidation FF = fully killed steel CEV < 0.45 / 0.53 for thickness 16 / 65 mm |
| C | Si | Mn | P | S |
| max 0.22 | max 0.55 | max 1.6 | max 0.03 | max 0.03 |
Mechanical properties of steel S355J2H (1.0576)
| Nominal thickness (mm): | to 3 | 3 - 100 | 100 - 120 |
| Rm - Tensile strength (MPa) | 510-680 | 470-630 | 450-600 |
| Nominal thickness (mm): | to 16 | 16 - 40 | 40 - 63 | 63 - 80 | 80 - 100 | 100 - 120 |
| ReH - Minimum yield strength (MPa) | 355 | 345 | 335 | 325 | 315 | 295 |
| KV - Impact energy (J) | -20° 27 |
| Nominal thickness (mm): | to 40 | 40 - 63 | 63 - 100 | 100 - 120 |
| A - Min. elongation at fracture (%) longitud., | 22 | 21 | 20 | 18 |
