Nickel 200 UNS 205 Duplex Stainless Steel Pipe 0.5 mm to 20 mm Wall Thickness
Production Name : Nickel Alloy Stainless Steel Pipes in grade Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
Nickel Products
NICKEL PIPES and TUBES:
All types of seamless & welded pipes & tubes are available in all sizes and grades.
Grade: Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
Size: 4mm OD to 219mm OD
Wall Thickness: 0.5mm to 20mm
NICKEL PLATES & SHEETS:
Grade: Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
Size: As per requirement.
Forms: Coil, Straight, Cut piece etc.
NICKEL ROD:
Grade: Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
NICKEL FITTINGS:
Grade: Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
Forms: Tees, Elbows, Cross, Coupling, Nipple, Bushing & others.
NICKEL FLANGES:
Grade: Nickel 200 (UNS 02200), Nickel 201 (UNS 02201), Nickel 205 (UNS 205)
Types:
Sockel weld flanges.
Slip on flanges.
Blind flanges.
Lap Joint flanges.
Weld Neck flanges.
Spectacle flange.
Customized flange.
Stock Size Range:
OD:1/2" through 6"
Wall:.Schedule 10 through Schedule 80
Specifications: ASTM B 161, ASME SB161
| Typical Chemical Composition % | |
| Nickel | 99.0 min |
| Iron | 0.40 max |
| Sulfur | 0.01 max |
| Carbon | 0.15 max |
| Manganese | 0.35 max |
| Silicon | 0.35 max |
| Copper | 0.25 max |
| Typical Mechanical Properties | ||
| Annealed | 1000 psi | Mpa |
| Yield Strength (0.2% offset) | 15 min psi | 105 |
| Tensile Strength | 55 min psi | 380 |
| Elongation % in 2 inches | 35 | |
Nickel Pipe Pictures :
