TP 904L 3 Inch Diameter Stainless Steel Pipe , Electric Fusion Welded Pipe
Product Name : Super Austenitic Stainless Steel Material : A403 S31254 904L 12" stainless steel pipe
Stainless Steel 904l Welded Pipes In Africa, Stainless Steel 904l EFW Tubes, Astm B677 SS 904l Seamless Pipes & Tubes Manufacturer & Exporter In India
SS DIN 1.4539 Rectangular Tubes In Europe, Stainless Steel UNS N08904 Round Pipe Exporter In South America, SS 904l Square Pipe Manufacturer & Suppliers.
Content
» Stainless Steel TP 904L Pipes & Tubes Specification
» ASTM B677 / B674 SS TP 904L Pipes Chemical Composition
» SS 904L Seamless Pipes & Tubing Mechanical Properties
» TP 904L Stainless Steel Pipes & Tubes Other Types
» Stainless Steel 904L Pipes Application Industries
» Packing Of SS 904L Pipes and Tubes Materials
However, there is limited use with hydrochloric acids. Stainless Steel 904L EFW Pipes is intended for use under severe corrosive conditions.Stainless Steel 904L ERW Pipes have excellent resistance to warm seawater and chloride attack.We manufacture these Stainless Steel 904L Tubing using optimum quality materials in a standardized manner. Offered products have high tensile strength. Besides this, these presented Alloy 904L Pipes are damage free in nature. Alloy 904L Tubes has some excellent features to offer such as thick frame, weather proof, smoothly finished, and more.
Stainlesss Steel 904L Pipes & Tubes Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | KS | EN |
| SS 904L | 1.4539 | N08904 | SUS 890L | Z2 NCDU 25-20 | 904S13 | STS 317J5L | X1NiCrMoCu25-20-5 |
TP 904L Stainless Steel Pipes & Tubes Chemical Composition :
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | CU | |
| 904L | Min | – | – | – | – | – | 19.0 | 4.00 | 23.00 | 1.00 |
| max | 0.20 | 2.00 | 1.00 | 0.045 | 0.035 | 23.0 | 5.00 | 28.00 | 2.00 |
Physical properties
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Elec Resistivity (nΩ.m) |
|||
| 0-100°C | 0-315°C | 0-538°C | At 20°C | At 500°C | |||||
| 904L | 8000 | 200 | 15 | – | – | 13 | – | 500 | 850 |
ASTM A312 / A213 SS TP 904L Pipes & Tubing Mechanical properties:
| Density | 8.0 g/cm3 |
| Melting Point | 1454 °C (2650 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Types Of Stainless Steel 904L Pipes Tubes Pictures
