Boat Docking Foam Boat Fenders Solid Filled Fenders To Protect Ships Iso 9001

Price Negotiable
Price: Negotiable
MOQ: 1pcs
Delivery Time: 5day
Brand: Henger
Product Description

Manufacturers Price Floating Foam Solid Filled Fenders To Protect Ships



Range of use:
1) Wharf and marine fender;
2) Applicable to gravity-type and Dun-type wharves, especially those with large tidal range;
3) It is especially suitable for the fenders where the ship is next to the ship, and the floating fender is more adaptable;
4) As a fender for bridge piers, protect the bridge piers and ships from damage;
5) As a necessary spare part of wharf protection equipment, it has a flexible emergency function;
6) It is suitable for the use of naval special ships to ensure the safety of berthing;
7) When the super large floating fender is used, the depth of the ship's berth can be increased to achieve the purpose of upgrading the dock;
8) The floating fender can be used alone, or it can be combined with other protective devices to protect the pier and the ship.





Foam filled fender, also called EVA solid fender, is a new type fender using light weight high elasticity foam as cushion medium, widely applied to harbour,offshore,STS and STD operation.
Henger Foam Filled Fender is made of environmental protection material and high elasticity polymeric material. Long service life and high economic value of this product is achieved by the high quality material with performance of high strength, high elasticity, high adhesion, anti-leakage,and aging resistance.











Has its characteristics:

1. High wear resistance is 3-5 times that of natural rubber


2. The oil resistance is 4 times better than nitrile rubber


3. High mechanical strength, its tear strength, tear strength and ability to bear load are many times higher than ordinary rubber


4. Excellent resistance to alkali, low temperature and solvent

5. High bonding strength with metal skeleton board



Technical Parameter

Model

D

(mm)

L

(mm)

compressibility 60%

Weight

(kg)

counter-force

(KN)

Energy Absorption

(KJ)

Ø 500×1000L 500 1000 71 8 34
Ø 600×1000L 600 1000 86 12 45
Ø 700×1500L 700 1500 161 27 101
Ø 1000×1500L 1000 1500 205 49 206
Ø 1000×2000L 1000 2000 274 64 275
Ø 1200×2000L 1200 2000 337 93 405
Ø 1200×2400L 1200 2400 390 110 475
Ø 1350×2500L 1350 2500 463 145 626
Ø 1500×3000L 1500 3000 624 216 927
Ø 1700×3000L 1700 3000 696 273 1191
Ø 2000×3500L 2000 3500 990 456 1923
Ø 2000×4000L 2000 4000 1110 505 2298
Ø 2200×4500L 2200 4500 1396 679 2992
Ø 2500×4000L 2500 4000 1386 781 3434
Ø 2500×5000L 2500 5000 1750 985 4272
Ø 3000×5000L 3000 5000 2050 1410 6411
Ø 3000×6000L 3000 6000 2460 1695 7293
Ø 3300×6500L 3300 6500 2950 2245 8335
Ø 4500×9000L 4500 9000 19650 7860

21460







If you have any interest or need, please feel free to contact me, I will always be there.

Thank you for reading.
