Metal Detector in Food Processing Industries, Industrial Metal Detector Conveyor
Price:
2800-3500
MOQ:
1 set
Delivery Time:
7-14 work days
Brand:
ZL
Product Description
Performance Features
- Advanced digital technology with original imported chips and potted detection coils for high accuracy and stability
- Multiple frequency settings with data storage for over 10 different products
- Intelligent recognition technology with self-learning and memory functions
- User-friendly LCD display with simple keypad interface
- Modular component design for easy replacement and maintenance
- Compliant with HACCP, GMP, and FDA requirements
- IP-66/IP-65 certified with shock, water, and dust resistance
- Multiple rejection device options available
Functional Types
All-Metal Detector
Detects all metals including iron, stainless steel, copper, and aluminum with high precision and stability.
Ferrous Metal Detector
Detects only ferrous metals with standard precision and sensitivity.
Aluminum Foil Metal Detector
Maintains high detection precision for ferrous metals even with aluminum foil packaging.
Technical Specifications
| Parameter | ZL-4001B Specifications |
|---|---|
| Detection Width | 400mm (Customizable) |
| Detection Height | 100-400mm (Multiple models available) |
| FE Sensitivity | ≥0.6-3.0mm (Depending on model) |
| Non-FE Sensitivity | ≥1.2-3.5mm (Depending on model) |
| SUS Sensitivity | ≥1.5-4.0mm (Depending on model) |
| Alarm Method | Automatic shutdown with 12V buzzer alarm |
| Machine Size | 1330×720×1000mm (Customizable) |
| Belt Material | Food grade PVC/PU Belt |
| Speed | 10-30 m/min |
| Machine Weight | 200-250KG |
| Power | 220V 50Hz, 120W (Customizable) |
| Load Capacity | Within 20KG (Customizable) |
| Storage Function | 99 products, 990,000 data |
Optional Features
- 7-inch touch screen with USB interface for data export
- Multiple rejection systems: duplicates, push rods, and air blows
Sensitivity parameters are approximate values from empty machine tests. Actual test parameters may vary depending on the test object.
