IEC60529 IPX6 Programmable Environmental Test Chamber For Portland Cement
The IEC60529 Programmable Environmental Dust Test Machine IPX6 for Portland Cement is designed for testing control cabinets, household appliances, low voltage electrical equipment, automotive components, lighting fixtures, motorcycle parts, and other product enclosures. This chamber maintains constant or variable pressure conditions, making it suitable for indoor low-concentration dust pollution testing to evaluate sample sealing integrity and corrosion resistance under these environmental conditions.
This LCD Touch Screen Programmable Dust Test Machine complies with GB4706, GB2423, GB7000.1, IEC60529 standards and meets IPX5 and IPX6 dust test requirements.
- Inner material: Stainless steel (SUS #304)
- Outer material: Powder-coated steel plate
- Imported touch screen programmable controller for dust blowing motor, dust vibration, and test time control
- Sealed chamber door with lock mechanism and glass observation window, equipped with interior lighting and dust brush
- Powerful dust blowing device and vibrator ensure uniform distribution during testing
- Frequency converter and high-pressure motor provide precise air volume control
- Large diameter stainless steel air hose with heating capability for dust drying
- Anti-explosion handle for safe and durable operation
- Imported high-precision electronic temperature, humidity, and air speed sensors
- Test sample differential pressure measurement with adjustable pumping rates
- ψ50mm test port with lid and silicone plug for external device connections
- Casters with brakes and leveling feet for mobility and stability
- Voltage/current indicators with DC12V/24V power supply options
- Complete vacuum system with pressure meter, filtration, and dehumidification
| Parameter | Specification |
|---|---|
| Test chamber dimension | 800 × 800 × 800 mm |
| Outer dimension | 1130 × 1250 × 1650 mm |
| Metal screen wire diameter | 50 μm |
| Screen line space | 75 μm |
| Environment temperature and humidity | 15–45°C, 45–75% RH |
| Dust (talcum powder) concentration | 2–4 kg/m³ |
| Test time | 0–999.9 hours (freely adjustable) |
| Test dust | Dry talcum powder or Portland cement |
| Test standards | GB4706, GB2423, GB7000.1, IEC60529 |
| Power supply | 3-phase 4-wire + Ground, 380 VAC, 50 Hz |
