HW76 Cab Heavy Duty Dump Truck For Normal Roads / Tough Roads Transportation
SINOTRUK HOWO 6x4 Euro II DUMP TRUCK 12 Wheeler With U-type cargo
Description:
HOWO brand. now is the hot sales brand of overseas market, the cab adopt all-steel forward control, 70° hydraulically tiltable to the front, 2-arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers .HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
Competitive Advantage:
1. It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.
2. Warranty: one year
3. Production time: within 35 working days
4. Shipping: we have logistic team, can cargo your truck fast and safety.
5. Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
.
|
Body |
Carriage Internal Dimensions(mm) | 5200x2300x1400 | |
| Cubage (m3) | 16.35 | ||
| Steel thickness of Carriage(mm) | Bottom:8mm;Side:6mm | ||
| Steel | Q235 | ||
| Hydraulic Lift of Carriage | Middle Lift | ||
|
Weight in kg |
Kerb weight (Kg) | 12270 | |
| Gross vehicle weight (Kg) | 30000 | ||
|
Dimension(mm)
|
Dimensions(mm) |
Length(mm) | 8045 |
| Width(mm) | 2550 | ||
| Height(mm) | 3450 | ||
| Wheel base (mm) | 3400+1350 | ||
|
Performance |
Maximum driving speed (km/h) | 75 | |
| Fuel consumption (1/100 km) | 38 | ||
|
Cab |
Model | SINOTRUK HW76 Lengthen cab | |
| HW76 cab, (single sleeping, with air-condition) | |||
|
Engine |
Model | WD615.69(Euro 2) | |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection | ||
| Horsepower | 336 | ||
| Maximum output Kw/r/min | 247/2200 | ||
| Maximum torque N.m/r/min | 1350/1300-1600 | ||
| Bore x Stroke | 126x130mm | ||
| Valve | 2 | ||
| Displacement | 9.726L | ||
| Transmission | HW19710 ,10 forward and 2 reverse | ||
|
Clutch |
SINOTRUK Φ430 diaphragm-spring clutch | ||
|
Steering |
ZF8118 Steering Gear Box(Left hand driving) | ||
|
Front Axle |
SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes. | ||
|
Rear Axles |
HC16,ratio:5.73 | ||
|
Brake System |
Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air operating on rear wheels |
||
|
Wheels & Tyres |
12.00R20 radial tyre with 1 Spare tire. |
||
|
Electrics |
Operating voltage:24V,negative grounded 24V,7.5KW.Starter:24V,7.5 Kw 28V,1500W.Alternator:3-phase,28V,1500 W 2x12V,165Ah.Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light |
||
| Oil Tank | Square type-400L Aluminum alloy fuel tank | ||
