266hp HOWO Euro II Heavy Cargo Truck 4x2 For Highway Transportation ZZ1167M5011W
ZZ1167M5011W HOWO 4x2 266hp Euro II cargo truck with HW15710 TRANSMISSION
Description:
The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.The engine adopt 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.
Packing:
Competitive Advantage:
1. The best quality standard guaranteed
2. Product upgrading and expansion of species
3. Good quality with competitive prices.
5. The price is competitive.
6. Excellent and high-quality control
7. Long lasting working life time.
| Vehicle Specifications | Model | ZZ1167M5011W | |
| Traction | 4x2 | ||
| Power | 266HP | ||
| Weight Parameter | Complete Vehicle Kerb Mass(kg) | 8000 | |
| Maximum authorized total mass(kg) | 16000 | ||
| Dimension Parameter | External Dimensions(mm) | Length (mm) | 8770 |
| Width(mm) | 2496 | ||
| Height(mm) | 2958 | ||
| wheelbase(mm) | 4600 | ||
| Internal cargo Sizes | Length(mm) | 6630 | |
| Width(mm) | 2280 | ||
| Height(mm) | 800 | ||
| Performance Parameter | Maximum Speed(km/h) | 102 | |
| Maximum Gradeability(%) | >40 | ||
| Turning diameter(m) | <16 | ||
| Recommended Configuration | Engine | Engine Type | WD615.62 |
| Rated power(kW)/Rev(r/min) | 196/2200 | ||
| Torque(N*m)/Rev(r/min) | 1300/1100-1600 | ||
| Transmission | HW15710 | ||
| Clutch(mm) | 430 | ||
| Axle | Front Axle | HF7 | |
| Rear Axle | ST16 | ||
| Fuel Tank(L) | 300 | ||
| Track(mm) | 2022+1830 | ||
| Front overhang/rear overhang(mm) | 1500/2270 | ||
| Tyre | 12.00-20 | ||
| Electrics | Operating voltage:24V,negative grounded | ||
| Brake system | Service brake: dual circuit compressed air brake | ||
