KHB High Pressure Hydraulic Ball Valves In Carbon Steel Max. Pressure 500 bar

Feature:

•  Hydraulic ball valves are designed according to DIN-ISO 1219
•  And the quality inspection for the hydraulic ball valves are according to DIN 55350 Part 18, the mill test certificates of the products are issued according to EN-10204 3.1.

Technical Specification

•  Metrial:Steel,Stainless steel
•  Seal:NBR, FPM, EPDM
•  Temperature Range(-25°C to +125°C)

QPE's high-pressure ball valves are designed to supply superior quality for optimum performance in an assortment of flap styles, sizes, and process connections.

•  no glands, so no manual readjustment of seals needed
•  The sealing principle is with floating ball seals on both sides
•  full-flow passing to guarantee unrestricted flow of oil, gas and water.
•  surface security phosphate-plated or yellowish zinc-plated
•  Lockable handle available.
•  Manufactured from cold worked stainless steel.
•  O-rings in material Viton, therefore the working temperature could be from 0°F (-17.8°C ) to 400°F (204°C).
•  Optional materials of O-rings available for high-temperature applications.
•  Penumatic and electric valve actuators available.
