5-20mm Plastic Pipe Production Line , Telecom Microduct Bundles Production Line
Telecom Microduct Bundles(TWD DB DI LSZH) PE Pipe Production Line
The increasing use of installing telecommunication and access network cabling in metropolitan and suburban areas is demanding. However, in metropolitan and suburban areas space is limited, and cabling should be down underground or on existing infrastructure. Traditional telecom cabling is facing
a big changllages for innovation.
KAIDE factory is the first company invented Telcom Microduct Bundles PE pipe production line to make the Telecom Duct Bundles preburied underground successfully.
→ Pipe Uncoiler
→ SJ60/36 PE jacketed layer Extruder
→ Microduct Bundles shaping device
→ Cooling flume
→ Haul-off machine
→ Winding machine
→ Siemens PLC control system
→ Remote control system
| Model | Screw Diameter |
L/D | Production Speed |
Line Length |
Nominal Power |
| KDJS-60 | 60mm | 36:01:00 | 30m/min | 38*4.5*2.5m | 109KW |
→ This Telecom Microduct Bundles Pipe making machine make a possible cabling solution for the growing and changing cities and neighborhoods's optical fibre and traditional cables telecommunictaion system. During the initial installation you don't need to know how the cable network will look like years ahead. Because using our machine you can produce a microduct network that can be altered easily afterwords.
→ The Telecom Microduct Bundles PE pipe production line can be customerized to design different types of Microduct Bundles, TWD(Thick Wall Duct), DB(Direct Bury), DI(Duct Install), LSZH(Low smoke zero Halogen) etc.
→ The Telcom Microduct Bundles make it possible for microduct cabling. High fibre density of low weight microduct cables combined with ease of handling these cables, increasing jetting speeds and improved duct and speace utilization result in reduced costs.
→ We can supply Telecom Microduct Bundles PE production line with a variety of duct combination ways.
We present only a fraction of our growing product range in this description. Contact us or visit our website to learn more about our products.
→ We can also modify and develop our products to fit your special requirement.
→ Telecommunication and network cables & optical fibre cables supplier are desired to find us to design HDPE Microduct tube Bundles PE pipe production line.
→ Especially popular in suburban and metropolitan areas construction materials industry.
