China High Hydraulic Cut Shutter Door Roll Forming Machine Siemens PLC System Full Automatic for sale

High Hydraulic Cut Shutter Door Roll Forming Machine Siemens PLC System Full Automatic

Price Negotiable

Price: USD18000~30000 Per Set

MOQ: 1

Delivery Time: 30-40days

Brand: Lebron

Product Description

High Hydraulic Cut Shutter Door Roll Forming Machine Siemens PLC System Full Automatic

1. Description of door shutter roll forming machine:

For the rolling shutter strip making machine, it is a machine will make shutter door slats, Our machine can do thickness for 0.3-1.4mm, the shape will be designed by your demand.

LBM is manufacturing high-quality guardrail roll forming machines and regularly exported to Turkey, Indonesia, Philippines, Malaysia, India, Angola, etc.

2. Technical details of door shutter roll forming machine:

Machine Specifications
Weight	About 3500kgs
Size	About 6m x 1.6m x 1.5m (length x width x height)
Color	Main color: blue
Color	Warning color: yellow
Suitable Raw Material
Material	Galvanized Steel Coils
Thickness	0.3-0.6mm
Yield Strength	235Mpa
Main Technical Parameters
Quantity of forming rollers stations	12-14
The diameter of forming rollers shafts	60mm
Roll Forming Speed	15-20m/min
Forming rollers material	No.45 steel, coated with a chromed treatment
Cutter material	CR12 mold steel, with quenched treatment
Controlling system	PLC and Converter
Electric Power requirement	Main motor power: 3kw
Electric Power requirement	Hydraulic unit motor power: 3kw
Electric voltage	According to customer’s requirement
