Durable Road Construction Machinery , Full Electric Atlas E Z Lift Pallet Truck With CE
New product Good Price Full electric atlas e z lift pallet truck with CE
1. German ZF drive unit, German mast, durable and good-looking
2. Japan SHIMADZU hydraulic pumping station
3. ZAPI electrical controller, reliable and easy to operate. Curtis electric controller available also
4. In addition to raising, lowering, forwards and backwards motions, the fork also can realize tilting motion
5. Max. Free lift (forks lift up and down but mast keep still) height reaches 3200mm
6. Forks could move forwards at 3 degrees and backwards at 5 degrees
7. Mast could move forwards and backwards with forks at 600mm
8. Powerful battery could guarantee for 10 hours continuous operating time per day
9. The mast needs to be disassembled in shipment due to height limit in container
10. Equipments with CE certificate
| Model No. | BR10/30 | BR10/50 | BR10/62 | BR15/30 | |
| Capacity | Q(kg) | 1000 | 1000 | 1000 | 1500 |
| Load Center | C(mm) | 500 | 500 | 500 | 500 |
| Net. Weight | kg | 2000 | 2500 | 2600 | 2300 |
| Free tail lift pallet trucking Height | H1(mm) | 1500 | 1700 | 1900 | 1500 |
| tail lift pallet trucking Height | H2(mm) | 3000 | 5000 | 6200 | 3000 |
| Overall Length | A1(mm) | 2260 | 2410 | 2410 | 2260 |
| Overall Width | B1(mm) | 1020 | 1020 | 1020 | 1020 |
| Overall Height | H3(mm) | 2086 | 2240 | 2640 | 2086 |
| Truning Radius | R(mm) | 1690 | 1690 | 1690 | 1690 |
| Run Speed(On load) | Km/h | 6/6.2 | 6/6.2 | 6/6.2 | 6/6.2 |
| tail lift pallet truck Speed(On load) | m/s | 0.19/0.2 | 0.19/0.2 | 0.19/0.2 | 0.19/0.2 |
| Driving Motor | kw | 2.0 | 2.0 | 2.0 | 2.0 |
| tail lift pallet trucking Motor | kw | 5.0 | 5.0 | 5.0 | 5.0 |
| Battery | V/Ah | 24/400 | 48/400 | 48/400 | 48/400 |
