lead edge feed pizza box 5 color middel speed Automatic Printing slotter and Die Cutting for Corrugated Paper Box

Automatic Four Color Flexo Printing and Die Cutting Printing Machine for Corrugated Paper Box

1. Machine technical parameter

2. Machine Details

The machine clutch

1) the machine clutch electric control with alarm, moving last warning bell ring, Ensure workers safety.

2) Pneumatic interlocking device

 Lead Feeder paper system

1) the suction feeder paper,fan 7.5 kw, at different levels can be bent according to the board, air volume adjustment, ensure feeding smoothly.

2) Carry paper,fall paper adopt cylinder push, move quick and powerful.

3)Side panel for manual adjustment, front and back panel are manual adjustment.

4) Taiwan super resistance to lead feeding wheel, Perishable Wear Resistant.

5)skip feeding paper device,( can choose according to need continuous or skip feeder paper).

6)Feeding counter, set, display production quantity .

 Feeder paper roller

1) . Outer diameter: 127 mm, up roller .

2).45 # seamless steel tube, parcel wear-resisting rubber, and do dynamic balance correction.

3)down roller,external diameter 127 mm, embossing and hard chromium plating , and do dynamic balance

correction .

4)feeder Paper roller gap dial manual adjustment, adjustment range 0-12 mm .

5)The former feeder paper rubber roller (elastic rubber roller) for dynamic lift and fall , automatic voltage regulator, can reduce the strength fracture of the corrugated board

3. Machine Photos

make out products picture :
