Product Application
RO water treatment, the raw water is tap water, first goes by pre-treatment, then by RO treatment. Through those treatments, can remove dissolving salt 99% and harmful materials, like particle, colloid, organic impurities, heavy metal ions, bacteria, viruses and heat source, etc. The system salt rejection rate gets 96-98%, outlet water conductivity gets ≤ 10μ S/cm².
Raw water source:Bore whole, river, well, mountain spring, lake, tap water, undergroud water etc
Filter media:Quartz sand filter, active carbon filter, security filter( PP filter)
RO Membrane:Hydranautics
Working process
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect.
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Micron filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump-- Provide the high pressure to RO membrane ro.
7.RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.
Main technical parameter of standard RO pure water machine
.
|
Type
|
RF-RO-500L/H(BY)
|
RF-RO-1T/H(BY)
|
RF-RO-2T/H(BY)
|
RF-RO-3T/H(BY)
|
RF-RO-4T/H(BY)
|
RF-RO-5T/H(BY)
|
|
Capacity(L/h)
|
500
|
1000
|
2000
|
3000
|
4000
|
5000
|
|
RO membrane
|
Brand: Hydranautics,USA Numbers:2 pieces 4040 RO
|
Brand: Hydranautics,USA Numbers:4 pieces 4040 RO
|
Brand: Hydranautics,USA Numbers:8 pieces 4040 RO
|
Brand: Hydranautics,USA Numbers:12pieces 4040 RO
|
Brand: Hydranautics,USA Numbers:4 pieces 8040 RO
|
Brand: Hydranautics, USA Numbers:4 pieces 8040 RO
|
|
Dimensions(mm)
|
1000*900*1650
|
2600*900*1925
|
3000*1000*2000
|
3200*1200*2360
|
4200*1450*2500
|
4200*1450*2500
|
|
Weight(KG)
|
185
|
450
|
560
|
680
|
850
|
980
|
Reverse Osmosis.
Reverse Osmosis is reverse migration movement of the infiltration.Driven by the pressure,its separation method which can seperate the solute and solvent in the solution with the help of semi-permeable membrane's interceptive roles.It has been widely used in the purification and concentration of various liquid.One of the most common examples is use in water treatment technics.With reverse osmmmosis technology,it can removev the inorganic ions,bacteria,viruses,and organic matter and colloidal impurities from the raw water,so as to obtain high-quality pure water.
Detail Pictures :
