Pressure Vessel 300psi 8040 4040 Frp Ro Membrane Housing For RO Water Plant
Top Quality Pressure Vessel 300psi 8040 4040 Frp Ro Membrane Housing For RO Plant
We also can call Pressure vessel, UF membrane, NF membrane, RO membrane Inside. It can contain 1 to 4 RO elements as 4 inch membrane housing and 1 to 6 RO elements as 8 inch membrane housing usually .
Our FPR membrane housings are applicabled to most standard membranes,products can also be manufactured for customer's special order.
DOW
HYDRANAUTICS
CSM
TORAY
Osmonics
FLUID SYSTEM
CHINESE BRAND
OTHERS
Main parameter Temperature: -7 - 50oC Max pressure: 300,600,1000psi
Operation pressure: 1.0-1.5Mpa;3.0Mpa; 5.5Mpa
Feed mode: End port entry( 4 inch); Side port entry( 8 inch)
Feed& Concentrate: 3/4" ( 4inch),1 1/2"( 8 inch);
Permeate: 1/2"( 4 inch),1"( 8 inch)
Fiberglass-Reinforced Plastics advantage
High Strength & Light Weight
Non-corrosive/Low Maintenance
Electrically Non-conductive
Easy to Assemble and Erect
Attractive Appearance
| Model |
Pressure, psi |
Connection | Membrane Size | Working Temperature |
| CK-4040-(1-4W)-300 | 300 | Side | 4040 | -7oC to 49oC |
| CK-4040-(1-4W)-450 | 450 | Side | 4040 | -7oC to 49oC |
| CK-4040-(1-4W)-600 | 600 | Side | 4040 | -7oC to 49oC |
| CK-4040-(1-4W)-800 | 800 |
Side |
4040 | -7oC to 49oC |
| CK-4040-(1-4W)-1000 | 1000 | Side | 4040 | -7oC to 49oC |
