Steam Heating Or Water Cooling Tank / Fermentation Tank Buffer Tank

Price Negotiable

Price: Negotiable

MOQ: 1 set

Delivery Time: 7-15 working days

Brand: Chunke

Product Description

Steam Heating Tank Water Cooling Tank Fermentation Tank Buffer Tank

Storage tank/mixing tank/blending vessel/emulsifying tank/jacketed kettle /reactor

Product Name	Storage tank/mixing tank/blending vessel/emulsifying tank/jacketed kettle /reactor
Description	Designed according to 3A standard, widely used for transfer viscous media in the food-processing, beverage, chemical, cosemtics and pharmaceutical industries
Construction	Horizontal and vertical; Open lid, flat, disc, conical, shell cover;
Material	SS304/SS316L/1.4301/1.4404
Seal Ring	Fluorine Rubber, EPDM, PTFE, Silicone(Standard, FDA approval)
Mechnical Seal	SIC, Hard alloy, graphite
Volume	50-50000L
Pressure	0-20 bar
Working temperature	300 C / 572 F
Jacket	Coil, dimple jacket, hollow jacket
Cooling	Water, coolant, compressor
Heating	Electric(water, oil), steam
Agitator	Stirrer, high shear homogenizer, scrap mixer
Agitator Speed	Constand speed and variable speed; Range: 0-4000rpm
Motor power	0.37kw-100kw
Voltage	110v/220v/240v/380v/415v/460v (50/60hz)
Motor	SIEMENS, ABB, Domestic
Automitac	PLC/HMI control, display, store, transfer
Surface treatment	Inner and externel polished and brushed, good weldings and joints;
Accessories	Customizable support
Availably connection	Clamp, Thread, Butt weld, Flange
Availably standard	DIN, SMS, 3A, RJT, ISO/IDF
Application scope	Dairy, food, beverage, chemical, pharmacy, cosmetic, etc
Packaging Details	Plywood case or customerized. Or as per the request of customers
Delivery details	Usually within 25 days after receiving T/T down payment, special customized need negotiation.
