FT-48V100Ah-LFeLi-5U UPS Solar &Wind power system Golf Cart Solar Strret LED Lighting

◆Use safety

◆Low self-discharge rate

◆Excellent high temperature performance

◆High cycle times and long life

◆High energy density and conversion efficiency

◆Environmentally friendly, free of any heavy metals

◆BMS Battery Management System with High Performance

◆Easy to install, 19 inch cabinet or wall mounted

Items and Specifications

Model                                          FT-48V100Ah-LFeLi-5U-A                  FT-48V100Ah-LFeLi-5U-B

Single cell battery                      IFR32700-6.0Ah-16S17P                    IFR32700-6.0Ah-15S17P

Nominal voltage                        51.2V                                                       48.0V

Nominal capacity (5HR)          100Ah                                                       100Ah

Discharge termination voltage 44.8V                                                      42.0V

Charging limit voltage               54.4V                                                       51.0V

Maximum charging current 30A

Maximum continuous discharge current 75A

Charging Current Limiting Maximum 20A

Display function is not available by default (optional)

Communication function default RS485/R232 (optional)

Dry contacts default no (optional)

Reverse connection/storage function

Parallel function: maximum support for 16 groups of parallel connection

Operating Temperature "Charging: 0-45 degrees Celsius"

Discharge: - 10 ~ 55 C

Storage: - 10 - 35 C“

Cyclic life (> 2000 cycles (0.2C charge 80% DOD) or more than 5 years

IP Level IP30

Shell Material Sheet Metal (White/Black)

Size (LxWxH) mm 436x385x222.5 (482.6 +1x420 +1x222.5 +1)

Weight: about 48 kg
