SINOTRUK HOWO 8x4 Cargo Truck With Mounted Crane

I. Abstract of cargo boom truck with mounted crane

Boom truck is mainly used for various loading and unloading, installation and lifting operations, especially for field lifting, rescue operation and narrow place operation.The boom truck crane is mainly composed of lifting, luffing, turning, lifting arm and chassis. The development of automotive cranes was facilitated by the development of hydraulic technology, the electronics industry, high-strength steel and the automotive industry. Mechanical driving boom truck crane with long working time has been replaced by hydraulic truck crane. The hydraulic system of the hydraulic truck crane adopts hydraulic pump, quantitative or variable motor to realize the lifting slewing, luffing, telescopic boom and telescopic leg of the crane, and can act alone or in combination. The motor is protected from overheating and has a safety device to prevent wrong operation.

II. SPECIFICATION

SINOTRUK HOWO 8X4 CARGO TRUCK WITH MOUNTED CRANE

Model: ZZ1317N4667W

Made Year: 2020, brand new, produced according to order

Cabin: HW76, long cabin, with single sleeper, with air

conditioner, with high position steel metal front bumper

Engine: WD615.47, 371hp, Euro II

Gearbox: HW19710, manual, 10 F & 2 R

Front axle: HF9, 2X9000kg, drum brake

Rear axle: HC16, 2X16000kg, drum brake, Ratio: 4.42/ 4.8/ 5.73

Suspension: reinforced leaf springs, front /rear 11/11/12 pcs

Tires: 315/80R22.5, tubeless, 13 pcs (including one spare tire)

Fuel tank: 400L, with locking cap

Without ABS

Steering: ZF8118, hydraulic operation with power assistance

Cargo Body: 7500*2300*600mm, thickness of bottom plate 3mm, thickness of side walls 1.5mm, with 14 ton crane

Overall Measurements: 12000x2550x3150mm

Color: White (yellow, blue, green, red, gray optional)

III. Features

1. SINOTRUCK boom truck adopt many key technologies both from home and abroad, and it can achieve the best design and be in good conditions.

2. HOWO boom truck have Low oil consumption. SINOTRUCK adopt the engine that combine the MAN and steyr technology, it has the perfect oil performance.

3. HOWO boom truck have comfortable and convenient in the Internal configuration of cabin.

4. HOWO boom truck have better heat dissipation,keep longer lifespan than other brand truck.
