Hydraulic Control 70T 1200KN HDD Horizontal Directional Drilling Machine

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 30 days

Brand: STETON

Product Description

HDD Horizontal Directional Drilling Machine Large Torsion ISO9001

Horizontal Directional Drilling Machine KEY point:

Powerful;

Fast travelling and tracking speed;

Can do the big piple line.

Horizontal Directional Drilling Machine Features:

Equipped with Cummins 264kw engine, large power, stable performance, lower fuel consumption, lower noise, more suitable working in city area.
Power head thrust and rotation adopts POCLAN motor, with large torsion, stable performance. Rotation have two speed , drilling faster and more torque; Thrust have 3 speed, let the work finished more faster. Thrust and rotation system both use hydraulic control system.
American style surface, looks so powerful.
Simple electric circuit design, low failure rate, convenient maintenance.
Equipped with φ89×3000mm drill rods moderate machine size adapts to narrow and small working area and high efficient construction as well.
Mud flow control system, can depends customer project save water.
Rod auto loading system , Auto anchoring system and push and pulling force increase to 70ton can be choose separate.

Horizontal Directional Drilling Machine Specifications:

Engine Power	KW	264/2200
Max Thrust force	KN	1200
Max Pullback force	KN	1200
Max Torque	N.M	43000
Max Rotary speed	Rpm	138
Max carriage speed	m/min	42
Max Mud pump flow	L/min	1000
Max Mud pressure	Mpa	8±0.5
Main machine size	mm	11700x2540x3000
Weight	T	24
Diameter of drilling rod	mm	Φ114
Length of drilling rod	m	6
Max diameter of pullback pipe	mm	φ150 – φ1000
Max construction length	m	1500
Incidence Angle	°	11～22
Climbing angle	°	14
