Right Hand Driving HOWO 340HP 18000liters 6*4 Compactor Garbage Rear Loader Truck
Product advantages:
-
Garbage Compactor Truck change the dirty appearance of the city and eliminate the secondary pollution.
-
It is equipped with computer control system for loading and unloading operations.
-
One Person operate that can reduce sanitation working time and greatly improves the working environment.
-
It install computer control system and manual operation system in order to improve the vehicle using rate.
Main structure:
-
Chassis
-
Garbage box; Lifting structure
-
Compressor and filling parts; Rear operation panel
-
Turnover mechanism/filling parts; Revocery water tank
-
Hydraulic tank; Manual operation panel
Types of compactor garbage truck:
-
All-sealing trash hopper
-
Triangle trash hopper
-
Swing arm trash hopper
-
Hanging bucket trash hopper
Specifications of 18CBM Garbage Compactor Truck
| Howo 18CBM Compressed Garbage Truck | |||||
| Overall Dimension | 9680*2550*3250mm | Gross Vehicle Weight | 25000 kg | ||
| Curb Weight | 13900 kg | Loading Weight | 11100 kg | ||
| Wheel Base | 5825+1350mm | Front / Rear Track | 7000 kg / 18000kg | ||
| Cabin | Right Hand Driving, 3 Passengers Allowed, with Air Conditioner, Radio, | ||||
| Engine Model | Diesel | ||||
| Engine horsepower | 340HP, EURO3 | ||||
| Max Driving Speed | 90 km/h | ||||
| Gear Box | 10 Forward, 2Reverse | ||||
| Tire | 12.00R20 (10 pieces with one spare) | ||||
| Garbage Bin | Capacity | 18CBM | |||
| Material | 5mm Carbon Steel for Garbage Bin Body | ||||
| Design | Whole unit with Leakage Proof Design | ||||
| Ways of Loading | Rear Loading with optional Bucket Lifting System | ||||
| Garbage Compact Ratio | 0.75tonns/cbm | ||||
| Control System | One control Panel on the back, One Control system in back of Cabin | ||||
| Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. | ||||
| 2. Automatic loading, compressing and discharging, all handled by 1 person | |||||
| 3. Sewage water collection tank to avoid any pollution during handling. | |||||
| 4. Large Pressure, Good Leakage Proof, Convenient Operation | |||||
| Dependable Security | |||||
| 5. Electrical Control Panel for compacting system. | |||||
| 6. Cycling time＜14~18s | |||||
| Remarks | 1. Color is optional | ||||
| 2. Customized LOGO painting as per customer request | |||||
Diagram
Working Show
Our Service
-
Quick feedback to solve your questions
-
Reasonable price and good quality
-
Quick delivery and shipment
FAQ
Q1: What kinds of garbage trucks I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2: Have you supplied garbage truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.
