Product: IQS450 204-450-000-001 Signal Conditioner in stock now

Description

IQS450 204-450-000-001 signal conditioner part of VM600. The IQS 450 signal conditioner contains an HF modulator/demodulator that supplies a driving signal to the transducer. This generates the necessary electromagnetic field used to measure the gap. The conditioner circuitry is made of high-quality components and is mounted in an aluminium extrusion.

Signal conditioner for use with proximity sensors (TQ).The IQS450 signal conditioner is a high-quality, high-reliability conditioner for use with the TQ4xx proximity sensors.The IQS450 is highly configurable (measurement range, sensitivity, total system length), and provides either a current output or a voltage output. It is designed and built for long-term use in environments characterised by hazardous areas (potentially explosive atmospheres).FeaturesSignal conditioning for TQ proximity sensorsVery wide frequency range (DC to 20000 Hz)Configurable transfer functionCurrent output for signal transmission over long distances or voltage output for signal transmission over medium distancesCertified for use in potentially explosive atmospheres PARAMETER VALUE (IMPERIAL | METRIC) Output type Current (2-wire) or voltage (3-wire) Measurement system TQ proximity Sensor TQ proximity sensors Frequency range DC to 20000 Hz Linearity See performance curves in data sheet Total measurement system length 3.3, 16.4 and 32.8 ft | 1, 5 or 10 m Operating temperature range ?22 to 185 °F | ?30 to 85 °C Protection rating IP40 Hazardous area certifications Ex ia, Ex nA
