12 AWG Silicone Coated Fiberglass Braided Wire For Coffee Maker UL3074
Price:
Negotiable
MOQ:
5000 pcs
Delivery Time:
7-10 working days
Brand:
MYSUN
Product Description
12AWG silicone coated fiberglass braided wire UL3074 lead wire
Specification:
Rated voltage: 600V
Rated temperature: 200C
UL standard: UL758, CSA
Applications: this wire widely sued for rice cooker, oven, sterilized cupboard and other home appliance, headlamp and etc.
Cable dimensions:
| Conductor | Insulation | Max.Cond Resistance | Unit length | |||
| Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal Thickness (mm) |
Diameter (mm) |
(Ω/KM) | (M)(Ft) |
| 12 | 19/0.47 | 2.36 | 1.03 | 4.42 | 5.53 | 100/328 |
| 65/0.254 | ||||||
| 7/0.78 | ||||||
Cable details:
Price term:
EXW, FOB, CIF
Payment terms:
LC, TT, Western Union and PayPal
Lead time:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
